Home > Instruments & Meters > Electronic Instrument > Oscilloscope > OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s

Name: OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s
Brand: OWON
SKU: 130771413

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s thumbnail-1

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s thumbnail-2

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s thumbnail-3

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s thumbnail-4

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s thumbnail-5

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s thumbnail-6

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s photo-1

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s photo-2

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s photo-3

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s photo-4

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s photo-5

OWON SDS8302 Digital Oscilloscope 2 + 1 Channel and 300MHz ,2.5GS/s photo-6

US$ 500 - 800 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

OWON

Model Number:

SDS8302

Contact Supplier Request Quote Chat Now

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENSHEN

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name OWON

Model Number SDS8302

OWON SDS8302 digital oscilloscope 2 + 1 channel and 300MHz ,2.5GS/s

OWON SmartDS Series digital oscilloscope
Product Series : Portable DSO

Main Features

- Bandwidth : 60MHz - 300MHz
- Sample rate : 500MS/s - 3.2GS/s
- 10M record length for each channel
- Multi-function : auto-scale, Pass / Fail, and current-measuring
- LAN remote control
- Newly supported SCPI
- Smart design with easy portability
- Large 8 inch 800 x 600 pixels display
- Optional battery available

Application

electronic circuit debugging circuit testing

design and manufacture education and training

automobile maintenance and testing

- See more at: .hk/products_info.asp?ParentID=0&SortID=0&ProID=172#sthash.4XiIwa6s.dpuf

Product Overview

Model No.	Bandwidth	Sample Rate	Record Length	Channel
SDS6062	60MHz	500MS/s	10M	2+1
SDS7072	70MHz	1GS/s
SDS7102	100MHz	1GS/s
SDS8102	100MHz	2GS/s
SDS8202	200MHz	2GS/s
SDS8302	300MHz	2.5GS/s
SDS9302	300MHz	3.2GS/s

Specifications

Model		SDS6062	SDS7072	SDS7102	SDS8102	SDS8202	SDS8302	SDS9302
Bandwidth		60MHz	70MHz	100MHz		200MHz	300MHz
Sample Rate		500MS/s	1GS/s		2GS/s		2.5GS/s	3.2GS/s
Horizontal Scale (s/div)		5ns/div~100s/div, step by1~2~5	2ns/div~100s/div, step by1~2~5		1ns/div~100s/div, step by1~2~5
Rise Time		≤5.8ns	≤5ns	≤3.5ns		≤1.7ns	≤1.17ns
Display		8”color LCD, 800 x 600 pixels, 65535 colors
Channel		2 + 1 (external)
Record Length		max 10M
Input Coupling		DC, AC, and GND
Input Impedance		1MΩ ± 2%, in parallel with 10pF ± 5pF
Channel Isolation		50MHz : 100 : 1, 10MHz : 40 : 1
Max Input Voltage		400V (PK - PK) (DC + AC, PK - PK)
DC Gain Accuracy		±3%
DC Accuracy		average≥16 : ±(3% reading + 0.05 div) for V
Probe Attenuation Factor		1X, 10X, 100X, 1000X
LF Respond (AC, -3dB)		≥10Hz (at input, AC coupling, -3dB)
Sampling Rate / Relay Time Accuracy		±100ppm
Interpolation		sin (x) / x
Interval (T) Accuracy (full bandwidth)		Single:±(1 interval time + 100ppm × reading + 0.6ns); Average>16 : ±(1 interval time + 100ppm × reading + 0.4ns)
Vertical Resolution (A/D)		8 bits resolution (2 channels simultaneously)
Vertical Sensitivity		2mV/div~10V/div
Trigger Type		Edge, Pulse, Video, Slope, Alternate
Trigger Mode		Auto, Normal, Single
Trigger Level		±6 divisions from screen center
Acquisition modes		Sample, Peak Detect, and Average
Line / Field Frequency (video)		NTSC, PAL and SECAM standard
Cursor Measurement		V, and T between cursors
Automatic Measurement		Vpp, Vavg, Vamp, Vrms, Freq, Period, Vmax, Vmin, Vtop, Vbase, Overshoot, Preshoot, Rise Time, Fall Time, Delay A→B↑, Delay A→B↓, +Width, -Width, +Duty, -Duty
Waveform Math		+, -, ×, ÷, FFT
Waveform Storage		15 waveforms
Lissajous Figure	Bandwidth	full bandwidth
	Phase Difference	±3 degrees
Communication Interface		USB, USB flash disk storage, Pass / Fail, LAN, VGA (optional), or COM (optional)
Cymometer		available
Power Supply		100V - 240V AC, 50/60Hz, CAT Ⅱ
Power Consumption		< 24W
Fuse		2A, T class, 250V
Battery (optional)		7.4V, 8000mA
Dimension (W × H × D)		340 × 155 × 70 (mm)
Weight (without package)		1.80 kg
