Specifications
New High Accuracy Digital MultiMeter MS8040 Top Multimeter 6300 Counts with Large Display
New High Accuracy Digital MultiMeter MS8040 Top Multimeter 6300 Counts with Large Display
l 6300 counts measurement
l ACV and DCV measurements reach up to 1000V.
l DC measurement accuracy reaches up to 0.03%.
l 0.1 Ω resistance resolution and 10μV voltage resolution.
l Linear frequency measurement, logic frequency/duty ratio measurement.
l Capacitance measurement from 0.001nF to 60mF.
l AC/DC true RMS measurement.
l Maximum value/minimum value measurement, relative value measurement.
l VFD double display function
l All operations by buttons
l Data logger saves data to Internal E2prom, USB-Disk or SD-Card.
l RS-232C, USB, Bluetooth communication interface can be choose.
l Display, record and graphics software of computer.
l Overload protection.
- Voltage between the measurement end and ground is of 1000V AC/DC. 1000V CAT I/600V CAT II, pollution degree 2.
- 6300 counts, automatic/manual range, basic sampling rate 2 t/s.
- When measuring mV, logic frequency, diode, resistance and capacitance, the maximum overload protection voltage will be 220V(RMS),while measuring of μA/mA the protection current being 0.64A,and measuring of A, the protection current being 10A.
- Over range indication OL.
- Fuse being 0.63A/1000V(μA/mA end) and 10A/1000V (A end) and 0.5A/250V(Power fuse).
- RS-232C/USB/BLUETOOTH/LAN interface.
- Operating temperature: 5°C~30°C(relative humidity 0~80%)
31°C~41°C (relative humidity 0~50%)
- Storage temperature: -20°C~60°C (relative humidity <= 80%)
- Altitude: Operation less than 2000m,
Storage less than 10000m
- Volume:350mm X 240mm X 100mm
- Weight:2500g
- DC Voltage
Range | Resolution | Accuracy |
60mV | 0.01mV | ±(0.03%+10) |
600mV | 0.1mV | ±(0.03%+6) |
6V | 1mV | ±(0.03%+6) |
60V | 10mV | ±(0.03%+6) |
600V | 0.1V | ±(0.03%+6) |
1000V | 1V | ±(0.03%+6) |
