Specifications
MS5208 Digital Multifunction Insulation Multimeter
MS5208 Digital Multifunction Insulation Multimeter
Features:
Conformance to IEC61010-1CAT 1000V
Dual display, large 6600 Counts LCD display.
Auto range and manual range.
True RMS for AC voltage and current.
Voltage/Current linear frequency measurement.
AC Voltage, AC Current with 1KHz 1 Low passed 1 filter.
Max, Min, AVG, and DIF Value measurement.
Can record up to 100 data.
Insulantion measure range 0.01MΩ to 2GΩ
Test voltage 50V/100V/250V/500V/1000V.
Live circuit detection & temperature test.
Timing measurement.
Polarization index and DAR function.
Low power indication,and auto power off.
With a portable carry bag.
Specifications:
DCV: 660mV/6.6V/66V/660V/1000V ±0.5%
ACV: 660mV/6.6V/66V/660V/750V ±1.5%
DC Current: 60mA/400mA ±1%
AC Current: 60mA/400mA ±1.5%
Resistance: 660Ω/66KΩ/660KΩ ±1.2%; 6.6MΩ/66MΩ ±2%
Capacitance: 6.6nF/66nF/660nF/6.6uF/66uF/660uF/6.6mF/66mF±5%
Temperature: - 30~1000 degree±2
Output Voltage Range Accuracy
50V(0% to 20%) 0~50MΩ ±5%
100V(0% to 20%) 0~100MΩ ±5%
250V(0% to 20%) 0~250MΩ ±5%
500V(0% to 20%) 0~500MΩ ±5%
1000V(0% to 20%) 0~2.0GΩ ±5%
Item size: 19.5 * 10 * 6cm
Item weight: 455g
Package size: 26 * 17.5 * 9cm
Package weight: 1075g
Including:
1 * Insulation Meter
1 * Test Leads
1 * Multi-function Socket
1 * Cable
2 * Clamps
2 * Batteries
Send Inquiry to This Supplier
