Help Center1/4"Swagelok Capsule Filter for Videojet,domino,Markem Imaje,CITRONIX Ink Jet Printer
Related Products
-
PTFE Capsule Filter 0.1micronUS$ 5 - 30MOQ: 10 Pieces -
PTFE Capsule Filter 1micron for Air and GasUS$ 5 - 30MOQ: 10 Pieces
-
PTFE Capsule Filter 1micron for the Chemical IndustryUS$ 5 - 30MOQ: 10 Pieces
-
PTFE Capsule Filter 1micron for Biological MedicineUS$ 5 - 30MOQ: 10 Pieces
-
N66 Capsule Filter 0.2micronUS$ 5 - 30MOQ: 10 Pieces
|
|
|
1 Pre-filteration before reverse osmosis and ultrafiltration;
2 Sample solution and the solvent filtration;
3 Inks and dyes, developing solution filtration;
4 Water samples filtration;
5 Higher flow rates of large sample volumes filtration;
6Sterilization analysis in food industry;
7 Liquid, tissue culture medium and small injection of the pharmaceutical industry and other liquid caustic solution filtration;
8 Photoresist in LCD production filtration;
9 Vent gas filtration;
10 Dyes in CD-R, DVD-R production in optical storage industry filtration;
11 Chemical industry, bio-pharmaceutical, laboratory and other solvents, liquid filtration
Material of Construction |
Filter membrane |
PP,PES,PVDF,PTFE,N6,N66,CN-CA,GF |
Diversion layer |
PP |
|
Housing |
PP |
|
Inner support |
PP |
|
Dimension |
Length |
2.5 ",5 ",10 " Other |
Filtration Ratings: |
PP |
0.10, 0.20, 0.45, 1.0, 3.0, 5.0, 10.0μm |
PES |
0.10, 0.20, 0.45, 0.65μm |
|
PTFE |
0.10, 0.20, 0.45, 1.0μm |
|
PVDF |
0.20, 0.45, 1.0μm |
|
Nylon |
0.10, 0.20, 0.45, 0.65μm,1.0μm |
|
Effective Filtration Area: |
2.5 " |
≥0.12 sq . m .
|
5 " |
≥0.25 sq . m . |
|
Operation condition |
PH Value |
1~13 |
Normal working temperature |
≤60℃ |
|
Max. Working temperature |
85℃, Differential pressure ≤0.10Mpa |
|
Max. Differential pressure |
25℃,forward 0.42Mpa,reverse0.21MPa |
|
|
Connections (Inlet/Outlet) |
1/8 "NPT |
3/8 "NPT HB |
1/4"NPT |
1/2"Swagelok |
|
1/8 "Swagelok |
3/8 "Swagelok |
|
1/4"Swagelok |
1/2"Swagelok |
|
9/16 "Conical hose |
8-12.8Conical hose |
|
1/4"-1/2" HB Conical hose |
Φ50.5Quick Open Interface |
|
Luer Lock |
Others |
|
Educt |
Endotoxin |
<0.25EU/ml |
Extractive |
<0.03g/10"cartridge |
