Rigol DM3068 6 1/2 Digit Digital Multimeter
DM3068 is a digital multimeter designed with 6 ½ digits readings resolution especially fitting to the needs of high-precision, multifunction and automatic measurement. It adopts many today's new technologies to achieve high performance, abundant features in the same class. It's designed to aim at therequirements of the largest DMM market from the research education,industrialelectronics,consumer electronics and automotive industries with its innovative technology,industry leading specifications,powerful measurement functions and broad analysis capabilities.
Features and Benefits
1)FeatReal 6 ½ digits readings resolution
2)Up to 10k rdgs/s Sample Rate ,512 K of Non-volatile Memory
3)True-RMS AC Voltage Current measuring
4)Built-in 10 groups data storage,10 groups setup storage
5)Standard temperature Sensor, built-in Thermcouple compensate in Cold terminal, support three types of temperature sensors: TC, RTD and THERM
6)Clone or backup all the configurations within instrument into other DM3068 via U-disc
7)UltraSensor software: Easy, convenient and flexible to support "Any sensor" measurements
8)Real time Trend and Histogram Display functions
9)Standard interface: USB Device, USB Host, LAN, RS-232, GPIB, support U-disc storage and Web remote control (LXI-C)
10)Remote control with SCPI commands
11)256×64 LCD
12)Support double display, Chinese and English menu
13)Push-help makes information acquire more easier
14)File management (support for U-disc and local storage)
1)Real 6.5 digits resolution
2)Easy to measure AC signal with double display
3)10 groups Preset function
4)standard capacitor measurement function
5)"amy sensor" function
6)Support multiple temperature sensors
7)Support multiple commands
8)file management(support U-disk and local storage)
9)math function
10)Statistic function
11)Histogram display
12)trendline display
RIGOL DM3068 Bench Digital Multimeter Technical Specifications
| Display | LCD display, 256 × 64 mm | |
| DC voltage | Range | 200 mV - 1000 V |
| Accuracy | 0.0035+0.0005 | |
| AC voltage | Range | 200 mV - 750 V |
| Accuracy | 0.06+0.03 | |
| DC current | Range | 200 µA - 10 A |
| Accuracy | 0.050+0.005 | |
| AC current | Range | 20 mA - 10 A |
| Accuracy | 0.10+0.04 | |
| Resistance (2-wire and 4-wire) | Range | 200 Ω - 100 MΩ |
| Accuracy | 0.010+0.001 | |
| Capacitance | Range | 2 nF - 10000 µF |
| Accuracy | 1 + 0.5 | |
| Frequency | Range | 43 Hz - 1 MHz / 1 µsec – 0.33 sec |
| Accuracy | 0.007 | |
| Interfaces | GPIB, LAN, USB 2.0 device and host, RS-232C | |
| Power | AC 100 V - 120 V, 45 Hz - 440 Hz AC 200 V - 240 V, 45 Hz - 66 Hz |
|
| Dimensions (H × W × D) | 107 × 231 × 290 mm | |
| Weight | 3.2 kg | |
RIGOL DM3068 Bench Digital Multimeter Package Contents
- RIGOL DM3068 multimeter (1 pc.)
- Test leads (1 pair)
- USB interface cable (1 pc.)
- Spare fuse (1 pc.)
- Power cord (1 pc.)
- CD with software (1 pc.)
- User manual (1 pc.)
