MS5205 2500V High Voltage Digital Insulation Tester Multimeter Megger Meter

Name: MS5205 2500V High Voltage Digital Insulation Tester Multimeter Megger Meter
Brand: Graigar
SKU: 130767037
Availability: InStock

US$ 90 - 120 MOQ: 1 Piece

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Graigar

Model Number:

MS5205

Shenzhen Graigar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Graigar

Model Number MS5205

Testing Voltage 250-2500v

Dimensions 180mm x 140mm x65mm

MS5205 2500V High Voltage Digital Insulation Tester Multimeter Megger Meter

Product Description

Model: MS5205

Features

INSULATION TESTS	Source Output Voltage		Measuring Range
	250V( 0 %~+20%)		0.01MΩ~250MΩ±(3%+5)
	500V( 0%~+20%)		0.01MΩ~500MΩ±(3%+5)
	1000V( 0%~+20%)		0.01MΩ~1000MΩ±(3%+5) 1.00GΩ~5.00GΩ±(5%+0.1GΩ) 5.00GΩ~10.00GΩ±(10%+0.2GΩ)
	2500V( 0%~+20%)		0.1MΩ~2.00GΩ(3%+5) 2.00GΩ~20.00GΩ±(5%+0.2GΩ) 20.0GΩ~100.0GΩ±(10%+2GΩ)
SHORT CIRCUIT CURRENT	2mA
Multimeter functions	DC Voltage Test	0.1~1000V±0.5%
	AC Voltage Test	0.1~750V±1%
	Continuity Test	0.01Ω~200Ω±0.5%
Features	» Design according to the IEC61010-1 1000V CAT Ⅲ 600V IV » Auto Calculate PI and DAR » Store /Load Function » Compare function » Auto discharge for capacitive load » Timer Function for insulation test » Lock function for insulation test » DCV and ACV Test » Continuity test » Auto Power Off » Digital and analog display
GENERAL
Power Supply	6x1.5v AA batteries
Product Size	180mm x 140mm x65mm (7.1” x 5.5” x 2.6”)
Product Weight	1050g(2.0lb)
Category	CE ETL CAT.Ⅲ1000v RoHS
