AC/DC Voltage MS5208 Professional Digital Insulation Meter Multimeter
Model: MS5208
Features
1.AC/DC Voltage
2.Continuity Test,Auto PI and DAR,CE certificate
3.High quality,CE certificate,Fast shippment,Warranty service
Specifications
6600 counts Digital Insulation Resistance Tester MS5208
AC/DC Voltage,Continuity Test,Auto PI and DAR,CE certificate
l Complies with IEC/EN 61010-1 1000V CAT III ,600 V CAT IV.
l 1000V DC Voltage,750V AC Voltage(TRMS).
l 6600 Count(except for capacitance,temperature,insulation).
l When the input terminals is V and COM,The overload protective voltage is up to AC 250 V (TRMS) ;When the input terminals is mA and COM, protective Current is 0.4A; when the input terminals is Hi and Lo , The overload protective voltage is 600V.
l Batteries:Four AA batteries (NEDA 15A or IEC LR6)Meter use 1000 hours; Insulation test use: Meter can perform at least 1000 insulation tests with fresh alkaline batteries at room temperature. These are standard tests of 1000 V into 1 MΩwith a duty cycle of 5 seconds on and 25 seconds off.
l Insulation Measurement Range : 0.01 MΩ to 2 GΩ.
l Insulation Test Voltages : 50, 100, 250, 500, 1000 V .
l Insulation Source Voltage: + 20 %, - 0 %.
l Insulation Short-Circuit Test Curren
