Specifications
Brand New AT510L 1Micro ohm Resistance Tester MeterBrand New AT510L 1Micro ohm Resistance Tester Meter
Item specifics
- Place of Origin:Jiangsu China (Mainland)
- Display Type:Digital Only
- is_customized:Yes
- Operating Temperature:0°C - 55°C
- Brand Name:Applent
- Accuracy Class:0.1%
- Measuring Range:1 micro ohm - 30 k ohm
- Dimensions:264mm(Width)*107mm(Height)*350mm(Depth)
- Model Number:AT510L
Product Description
AT510L DC Resistance Meter | ||
SPECIFICATIONS | ||
Parameter |
DC resistance |
|
Accuracy |
0.1% |
|
Measurement Range |
1μΩ~30kΩ |
|
Signal Source |
I - Max: < 1A |
|
Range |
Automatic and manual with 7 ranges |
|
Speed |
15 times/second 10 times/second 2 times/second |
|
Result Display |
Show, ΔABS, Δ% and sorting result |
|
Max Reading |
30,000 |
|
Adjustment |
Short-circuit Zero-Adjust for each range REL function |
|
Comparator |
NG-LO, GD-IN, NG-HI display and output adjustable beep and volume |
|
Interface |
None |
|
Method |
Four-terminal |
|
Others |
Four-color vacuum fluorescent display screen VFD display Keypad lock and data hold function High-cost performance |
|
GENERAL FEATURES | ||
Power Supply |
Voltage: 198V AC - 240V AC Frequency: 50Hz Power: Max 15VA |
|
Dimension & Weight |
Outside: 264mm (Width)x107mm (Height)x350mm (Depth) Inside: 216mm (Width)x88mm (Height)x323mm (Depth) 4kg |
|
OREDERING INFORMATION | ||
Accessory |
AT501: Kelvin clip |
|
Optional accessory |
L620: Four-terminal meter resistance clip |
|
