Help CenterTM-2013 TRMS AC/DC Clamp Meter,CAT IV 600V, CAT III 1000V LCD Backlit Display, With Maximum Reading of 6600
Related Products
-
TM-3013 AC/DC Clamp MeterUS$ 160 - 170MOQ: 1 Piece -
KSR-2017 Digital Clamp MeterUS$ 40 - 50MOQ: 1 Piece
-
ACA Clamp Meters,Clamp Meters,Clamp Meter,Digital Power Clamp Meters,ACA & DCA Clamp Meters With True RMS,ACA & DCA Clamp MetersNegotiableMOQ: 1 Piece
-
ACA Clamp Meters,Clamp Meters,Clamp Meter UT202NegotiableMOQ: 1 Piece
-
Double Injection Outer Case TM-2011 660A AC Clamp MeterUS$ 150 - 160MOQ: 1 Piece
Specifications
Product DescriptionCAT IV 600V, CAT III 1000V
LCD backlit display, with maximum reading of 6600.
AC voltage range: 0 to 750
TM-2013 TRMS AC/DC Clamp meter,CAT IV 600V, CAT III 1000V LCD backlit display, with maximum reading of 6600
Product Description
CAT IV 600V, CAT III 1000V
LCD backlit display, with maximum reading of 6600.
AC voltage range: 0 to 750V.
AC current range: 0 to 660A.
DC voltage range: 0 to 1000V.
DC Current: 0 to 660A.
Resistance measurement to 66 megohms.
Data Hold, Min/Max, Autoranging, DCA Zero.
Test Ranges: ACV, ACA, Resistance, Frequency, Diode, Continuity.
Work light.
Auto Power Off.
Double Injection outer case.
- Specification
Maximum Current |
660 Amps |
Display |
6600 counts |
Max. Conductor Size |
40mm |
AC Current |
0.1A to 660A |
DC Current |
0.01A to 660A |
DCA |
Zero Adjustment |
AC Voltage |
0.1mV to 750V |
DC Voltage |
0.1mV to 1000V |
Resistance |
0.1Ω to 4000Ω, |
Continuity Buzzer |
Yes |
Diode |
Test voltage |
Frequency |
1Hz to 660KHz |
True Rms |
Yes |
Backlit Display |
Yes |
Work Light |
Yes |
Autoranging |
Yes |
Auto Power Off |
Yes |
Inrush |
Yes |
Data Hold |
Yes |
Min/Max |
Yes |
Dimensions |
252mm (L) x 91mm (W) x 22mm (D) |
