Low Voltage Withdrawable Switchgear Assemblies
ABOUT SHOUGUANG JUNENG ELECTRIC CO., LTD
Feature
1. MNSJ is designed acc to ABB global standard to meet the need of industrial development.
pact design. smaller space and more functional units.
3.flexible structure. C type profile in 25mm modulus could satisfy various structures,protection grade and service environment.
4.standardized design. it has function units for protection, operation, conversion, control, adjustment, test and indication.
5.high technical performance. the main parameters could reach the international advanced level.
6.easy to assemble and maintenance.
| Electrical characteristics | ||
| Rated insulation voltage | 1000/AC | |
| Rated operational voltage | 680/AC | |
| Rated impulse withstand voltage | 12kV | |
| Overvoltage category | 4 | |
| Degree of pollution | 3 | |
| Rated frequency | up to 60Hz | |
| Main busbars | ||
| Rated current | up to 6300A | |
| Rated peak withstand current | up to 220kA | |
| Rated short-time current | up to 100kA | |
| Distribution busbars | ||
| Rated current | up to 1200A(2000A) | |
| Rated peak withstand current | up to 110kA (170kA) | |
| Rated short-time current | up to 50kA (80kA) | |
| Strucutural characteristics | ||
| Dimension | ||
| Cabinet and component | DIN41488 | |
| Recommended height | 2200mm | |
| Recommended width | 400/600/800/100/1200mm | |
| Recommended depth | 600/800/1000/1200mm | |
| Module | E=25mm | |
| Protection grade | according to IEC529 or DIN41060 | IP30 - IP54 |
payment terms & packing
1.payment terms: T/T with 30% deposit or L/C
2.packing detail: wooden case or at the requirement of customers
3.delivery time: usually within 30 days after the deposit
What we can do better
- Quality Assurance--From the very beginning, JUNENG ensures quality in every step to achieve the best quality.
- Experience Sharing--With over 10 years’ experience in power industry, JUNENG brings you an optimized solution.
- Quick Response--In response to your needs without delay, JUNENG knows the value of your time.
LV Switchgear Display
Workshop & Equipment
certificate
Any inquiry or question, pls contact me.
