floor scale load cell, axle scale load cell

other dimension

KLB

L

L1

B

H

H1

D1

D2

R1

R2

25~50

209.5

184.2

51

51

64

50.8

41.4

12,7

12.7

60~75

292.1

254

51

63

76

56

43.2

25.4

19

100

368.3

317.5

73.7

78

99

81.3

62

38.1

25.4

Specification

comprehensive error:

0.2%FS

output resistance:

350±5Ω/700±5Ω

Rated output:

2±0.05mv/v

Insulation resistance:

≥5000MΩ(100VDC)

Non-linearity:

0.2%FS

Excitation voltage:

9~12VDC

Hysteresis:

0.1%FS

compensated temp:

-10~+40°C

Repeatability:

0.05%FS

use temperature:

-35~+65°C

Creep:

0.05%FS/10MIN

temp effect on zero:

0.05%FS/10°C

Zero balance:

±1%FS

Temp effect on span:

0.05%FS/10°C

Input resistance:

350±5Ω/700±5Ω

defend grade:

IP66 & IP68
