Specifications
balance machinebalancing machine
turbo balancer
turbocharger balancing machine
Windows XP operation system
Technical Data:
MODEL |
Mass of workpiece (kg) |
Max.diameter of workpiece (mm) |
Distance between two support bearings (mm) |
Range of journal diameter (mm) |
Balancing speed (rpm) |
Min. achievable residual unbalance(g.mm/kg): |
Unbalance reduction ratio(%): |
Drive power (kw) |
RYQ-3 |
0.1-3 |
350 |
30-450 |
3-22 |
400-10000 |
<=0.5 |
>=90 |
0.09 |
Features:
soft bearing horizontal dynamic balancing machine, using the belt drive, is variable-frequency electromotor plus inverter speed, industrial control computer data processing, color screen real-time shows the value of the amount of unbalance ,phase and real-time rotational speed, bases have adopted the overall foundry, stability is good. It is widely applied in engine,wind motor, blower, diesel engine and auto parts and other range, It can balance and measure on single side, double side and many test sides, fit for axial, plate and gravity out-stretching roller. It has characterstics of high efficency, correct precision, direct display, good quality, convenient maintenance and so on, the soft has both common work piece and standard roller special functions, avoid demarcate equipment non-automatically for customers who use other hard support balancing machine measure system, and you can choose many measure method and function, it can realize to input parameter, preview, test, save results, type, use chinese menu to operate, man-machine conversation, auto prompting.
Detailed Photos
