Principal Axis Dynamic Balancing Machine YYW-160A
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
TC
Model Number:
YYW-160A
Power:
Electronic
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Axis Dynamic Balancing Machine YYW-160ANegotiableMOQ: 1 Set -
Universal Joint Drive Balance Machine YYW-160ANegotiableMOQ: 1 Set
-
Balance Machine, Horizontal Hard Bearing Balancing Machine YYW-160ANegotiableMOQ: 1 Set
-
Rotator Balancing Machine YYW-160ANegotiableMOQ: 1 Set
-
Horizontal Balancing Machine YYW-160ANegotiableMOQ: 1 Set
Brand Name
TC
Model Number
YYW-160A
Power
Electronic
Usage
Balancing Machine
Specifications
balance machinedynamic balancing machine
principal axis balancing machine
Windows XP operation system
universal joint drive
Features:
Hard bearing horizontal dynamic balancing machine;
Using the wheel backing, universal coupling to drive;
Variable frequency control motor;
Industrial control computer data processing, color screen real-time shows amount and angel of unbalance, and rotational speed;
Bed is overall foundry with good stability
Balance and measure on single side, double side
Technical Data:
Model |
Max. mass of workpiece(kg) |
Max.diameter of workpiece(mm) |
Distance between two support bearings(mm) |
Max.rotor Diameter(mm) |
Balancing speed(rpm)
|
Min. achievable residual unbalance(g.mm/kg): |
Unbalance reduction ratio(%): |
Drive power (kw) |
YYW-160A |
5-160 |
950 |
60-1420 |
10-180 |
300-2500 |
<=1 |
>=90 |
1.5 |
Photos:
