Specifications
balance machinebalancing machine
universal hard bearing balancing machine
CE certified
Windows XP operation system
Features:
Hard bearing horizontal dynamic balancing machine;
Using the wheel backing, universal coupling to drive;
Industrial control computer data processing, color screen real-time shows the value of the amount and angel of unbalance and rotation speed;
Bed is overall foundry with good stability
Balance and measure on single side, double side
Warranty period:
Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.
Technical Data:
Model |
Mass of workpiece(kg) |
Max.diameter of workpiece(mm) |
Distance between two support bearings(mm) |
Range of Journal Diameter(mm) |
Balancing speed (r/mm)
|
min. achievable residual unbalance(g.mm/kg): |
unbalance reduction ratio(%): |
Drive power (kw) |
YYW-300A |
10-300 |
φ1200 |
60-1700 |
φ20-180 |
300-2500 |
≤1 |
≥90 |
5.5 |
