Solar Module System High Efficiency pv Panel Kits

Solar Module System High Efficiency pv Panel Kits thumbnail-1
Solar Module System High Efficiency pv Panel Kits thumbnail-2
Solar Module System High Efficiency pv Panel Kits photo-1
Solar Module System High Efficiency pv Panel Kits photo-2
US$ 0.45 - 0.55 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GH
Model Number:
GH016 130W
Contact Supplier Request Quote Chat Now
Zhejiang Ganghang Solar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GH
Model Number GH016 130W
Material Polycrystalline Silicon
Size 156
Number of Cells 36
Max. Power 130W
solar module system high efficiency pv panel kitssolar module system high efficiency pv panel kitssolar module system high efficiency pv panel kits

Solar Panel

MODEL  WP(W)   ARRANGEMENT MODEL    SIZE(L*W*H)   Vmp(V)   Imp(A)   Voc(V)   Isc(A)
GH034   280W   156*156P/M  6*12PCS   1956*992*50MM   37.20        7.55        45.20     8.44
GH033   260W   156*156P/M  6*12PCS   1956*992*50MM   36.60        7.14        44.10     8.10
GH032   240W   156*156P/M  6*10PCS   1650*992*50MM   31.00        7.75        37.20     8.54
GH031   220W   156*156P/M  6*10PCS   1650*992*50MM   30.60        7.25        36.60     8.31
GH030   200W   156*156P/M  6*9PCS     1476*992*45MM   28.00        7.24        33.20     8.14
GH029   180W   156*156P/M  6*8PCS     1650*836*50MM   24.80        7.26        30.75     8.15

GH018   150W   156*156P/M  4*9PCS     1476*680*35MM   18.00        8.35        22.20     8.85
GH017   140W   156*156P/M  4*9PCS     1476*680*35MM   18.00        7.80        22.20     8.67
GH016   130W   156*156P/M  4*9PCS     1476*680*35MM   17.20        7.56        22.20     8.50
GH015   120W   156*156P/M  4*9PCS     1476*680*35MM   17.20        7.05        21.60     8.40
GH014   110W   156*120P/M  4*9PCS     1150*680*35MM   17.20        6.40        21.60     7.20
GH013   140W   156*120P/M  4*9PCS     1150*680*35MM   17.20        5.90        21.60     7.00





MODEL  WP(W)   ARRANGEMENT MODEL    SIZE(L*W*H)   Vmp(V)   Imp(A)   Voc(V)   Isc(A)
GH028  255W     125*125M  8*12PCS     1580*1060*45MM   48.60        5.25        59.10     5.51
GH027  240W     125*125M  8*12PCS     1580*1060*45MM   48.00        5.01        59.00     5.40
GH026  230W     125*125M  8*12PCS     1580*1060*45MM   48.00        5.00        58.60     5.35
GH025  220W     125*125M  8*12PCS     1580*1060*45MM   47.50        4.65        58.00     5.25
GH024 195W      125*125M  6*12PCS     1580*808*40MM     37.20        5.25        44.20     5.52
GH023 190W      125*125M  6*12PCS     1580*808*40MM     37.00        5.15        44.20     5.45
GH022 185W      125*125M  6*12PCS     1580*808*40MM     36.60        5.10        43.20     5.40
GH021 180W      125*125M  6*12PCS     1580*808*40MM     36.60        5.00        43.20     5.35
GH020 175W      125*125M  6*12PCS     1580*808*40MM     36.20        4.85        43.20     5.25
GH019 170W      125*125M  6*12PCS     1580*808*40MM     36.60        4.75        43.00     5.10

GH012  95W       125*125M  4*9PCS       1200*550*35MM     18.00        5.27        22.60     5.55
GH011  90W       125*125M  4*9PCS       1200*550*35MM     18.00        5.10        21.60     5.45
GH010  85W       125*125M  4*9PCS       1200*550*35MM     17.20        5.00        22.60     5.35
GH009  80W       125*125M  4*9PCS       1200*550*35MM     17.20        4.80        21.60     5.25
GH008  75W       125*125M  4*9PCS       1200*550*35MM     17.20        4.41        21.60     5.10
GH007  70W       125*125M  4*9PCS       1200*550*35MM     16.80        4.20        21.60     4.90
