SOLAR PANEL,SOLAR SYSTEM,SOLAR MODULE
1.What is 100% TUV standard flash test?
Flash test machine with TUV standard reference solar panel,all Propsolar Panel is tested with 100% TUV standard or standard higher than TUV standard
In the market,not all solar panel is real tested with TUV standard,Flash machine reference panel is not TUV standard,so the power is 2%-3% less than TUV standard
2.Descprition:
PS-P672 Series solar panel is connected in series by 72 pieces of 156mm×156mm Poly Crystalline silicon cells. PS-P672 Series solar panel includes 245W, 250W, 255W, 260W, 265W, 270W, 275W, 280W, 285W,290W, 295W.
3.Characteristics
1)Manufactured according to international quality and Environment Management
System (ISO9001, ISO14001)
2)High efficiency crystalline silicon solar cells
3)High transmission Iow iron tempered glass, strong mechanical resistance
4)Anti-ageing EVA and excellent anti-climate back sheet
5)Anodized aluminum frame improves load resistance capabilities for heavy wind loads.
6)Standard waterproof junction box
7)High endurance to different weather
8)Good and friendly package with less transportation and storage space.
4.Warranty
1)10 years limited manufacturing warranty
2)12 years for 90% of warranted minimum power
3)25 years for 80% of warranted minimum power
5.Electric Characteristics
CELL TYPE |
156 X 156 POLY SOLAR CELL |
||||||||||
ITEM |
245W |
250W |
255W |
260W |
265W |
270W |
275W |
280W |
285W |
290W |
295W |
Maximum Power(Wp) |
249.9 |
254.9 |
259.9 |
264.9 |
269.9 |
274.9 |
279.9 |
284.9 |
289.9 |
294.9 |
299.9 |
Open circuit Voltage (Voc) |
42.4 |
42.8 |
43.3 |
43.5 |
43.8 |
44.3 |
44.6 |
44.9 |
45.1 |
45.3 |
45.5 |
Short circuit Current (Isc) |
7.60 |
7.65 |
7.75 |
7.90 |
8.05 |
8.15 |
8.25 |
8.40 |
8.55 |
8.70 |
8.85 |
Maximum Power Voltage (Vm) |
34.9 |
35.1 |
35.4 |
35.5 |
35.7 |
36.0 |
36.2 |
36.3 |
36.4 |
36.5 |
36.6 |
Maximum Power Current (Im) |
7.02 |
7.12 |
7.20 |
7.32 |
7.42 |
7.50 |
7.60 |
7.71 |
7.83 |
7.95 |
8.07 |
Features
1.Product name:Solar panel/module
2.Tempered glass laminated with aluminum frame
3.Life time:20-30 years
4.Temperature co-efficiency:A=+1,46mA, B=-79mV,Rp/p=0.43
5.Power specification at 1kw/m2
6.Output cable:Multi contact connectors
7.Diodes:Three 10A,1KV schottky by pass diodes included
8.Construction:
a.Fromt high-transmission 32mm tempered glass
b.Back:TPT
c.Encapsulant:EVA
9.Frame:Aluminum alloy
