Specifications
solar energy company solar panel 2000wattsWe are engaged in supplying solar panel, solar cell and solar system.
solar energy company solar panel 2000watts
We are engaged in supplying solar panel, solar cell and solar system.
Photovoltaic Solar Panel Data Sheet | |||
Description of Specification |
Configuration |
Units |
Model BA-M280 |
| |||
General Data | |||
Maximum Power |
Pm(W) |
Watts |
280W |
Power Tolerance |
|
% |
±3 |
Application |
|
|
~ |
Storage & Operating Temperature |
|
Deg .C |
-45~85 |
Certificates |
|
|
UL,TUV,ISO,CE,ROTHS,IEC..Etc |
Cell Efficiency |
|
|
18% |
| |||
Voltage & Ampereage |
|
|
|
Maximum System Voltage |
|
Volts |
1000VDC |
Maximum Operating Voltage |
Vmp |
Volts |
36 |
Maximum Operating Current |
Imp |
Amps |
7.78 |
Open Circuit Voltage |
Voc |
Volts |
43.2 |
Short Circuit Current |
Isc |
Amps |
8.71 |
|
|
|
|
Solar Cell | |||
Cell Type and Diameter |
|
|
Monocrystalline,156mm |
Number of Cells |
In Series |
|
72(6×12) |
|
|
|
|
Other parameter |
|
|
|
Standard Test Conditions:Cell Temperature:25 Deg. C,Irradiance:1kW/m2,Air Mass: 1.5 | |||
Maximum wind resistance: 60m/S(N/Square meters or max Km/h) | |||
Surface maximum load capacity: 200 (Kg/Square meters) | |||
Impact resistance hail impact test: 25mm(at 80km/h) | |||
|
|
|
|
Temperatures Coefficients | |||
Temp Coefficent of Isc |
Tk Isc |
% per deg.C |
0.05 |
Temp Coefficent of Voc |
Tk Voc |
% per deg.C |
-0.34 |
Temp Coefficient of Pmax |
Tk Pmax |
% per deg.C |
-0.45 |
Normal Op. Cell Temp (NOCT) |
|
deg.C |
45±2 |
|
|
|
|
Materials & Accessories Data (All Certified by CE and TUV) | |||
Standard waterproof Junction Box |
|
|
IP65 rated |
Output Cable:Wire Diameter :4m |
Length |
mm |
900 |
Type of Cable Connector |
|
|
MC Plug Type IV |
Frame:Aluminum Alloy |
|
|
Anodized |
Front Glass:Low Iron,High Transmisson,Tempered glass |
Thickness |
|
3.2mm |
Cell Encapsulation Material |
EVA |
mm |
0.5mm |
Backsheet Cover Material |
TPT |
mm |
0.3mm |
|
|
|
|
Quality Warranty |
|
|
|
Materials and workmanship |
|
Years |
5 |
Output Power Warranty |
90% |
Years |
10 |
80% |
Years |
25 |
|
|
|
|
|
Dimensions, Packing & Weight |
|
|
|
Dimensions:Length×Width×Height |
|
|
1960*986*50MM |
Weight |
|
kg |
23KG |
Packing |
|
|
Carton, pallet,container |
Leadtime |
|
|
According to order detail |
Features:
1. High efficiency soalr cells operate perfectly under both optimal and low light conditions, Cells assembled in modules with a tight,strict range for better performance to ensure optimal operation.
2. Antireflective coatings and High Transmission Low Iron Glass to increase module output.
3. Sealed Junction box filled with resin to keep moisture out ,and highest quality EVA and sealants to further protect against moisture.
4. Strong aluminium frames made from anti-corrosion(anodised) to protect perfectly sealed module.
5. High-Impact tempered glass to resist hail, Ice, flying debris or force wind.
6.high quality Anti-ageing/anti-UV EVA and excellent anti-climate high frame resistant back sheet to laminate.
7. Innovative, environmentally friendly packing method using pile-edges ensures modules arrive in perfect condition.
8.High performance bypass diodes prevent damage through overheating due to shaded or defective cells.
..etc
If you want to get more information please ask me feel free, my Skyp: cathfang1232, hope we could give you best support in near future.
