Green Energy 5000W Solar Power System for Home Use

Name: Green Energy 5000W Solar Power System for Home Use
Brand: GH soler energy
SKU: 130618487
Availability: InStock

US$ 0.78 - 1.2 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GH soler energy

Model Number:

GH-6082

Zhejiang Ganghang Solar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/ Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GH soler energy

Model Number GH-6082

Specification Normal

Application Home

Output Voltage (V) 36

Load Power (W) 180

Solar Power (W) 18%

Work Time (h) 12

Specifications

green energy 5000W solar power system for home use
We are engaged in the designing, producing solar module

solar electricity

off-grid 5000w solar power generator
Capacity- 5000VA
Rated output power- 5000W
Solar Module -1600W
Battery- 216V/100Ah

off-grid 5000w solar power generator

Technical Data

Capacity	5000VA
Rate Output Power	5000W
Output wave	Pure sine wave
Output current	18.2(220V)/36.4A(110V)
PREcision of output voltage	±3%
Precision of output frequency	±0.1%
False output wave of AC	less than 3%
Power factor	0.8
Overload ability	120%, 30 seconds
Invert efficiency	More than 85%
Output voltage	220VDC
Output frequency	50HZ/60HZ
Maximum output power of Solar Module	1800W
Maximum output voltage of solar module	315V
Maximum output current of solar module	5.7A
Battery capacity	216V100AH
Best output power everyday	6756WH

Package data:

Package Measure of power box	500640930
G.W.of power box	65KG
Package Measure of solar cell	1200850765
G.W. of solar cell	203KG
Package Measure of bracket	227085450
G.W. of bracket	113KG
Package Measure of battery	740625835
G.W. of battery	520KG
20'	14
40'	35

green energy 5000W solar power system for home use

Reference: Max Power Supply Capacity

Name of Load	Model	Power	Quantity	Working Time per Day (H)	Continued Working Days
Color TV		65	1	6	3 continued overcast and raining days
Satellite TV Receivers		25	1	6
LCD Computer		100	1	2.5
Energy-saving lamp		11	6	6
Printer		30	1	1
Electrograph		150	1	1
Water Pump		200	1	1
Refrigeratory		100	1	24
Washing machine		300	1	0.5
Air condition		1200	1	5
