Sunpower pv Solar Panel Module System

Sunpower pv Solar Panel Module System thumbnail-1
Sunpower pv Solar Panel Module System photo-1
US$ 0.78 - 1.2 MOQ: 100 Watts
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
GH solar
Model Number:
GH-5402
Contact Supplier Request Quote Chat Now
Zhejiang Ganghang Solar Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/ Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name GH solar
Model Number GH-5402
Material Monocrystalline Silicon
Size 1650*992*50mm
Number of Cells 72
Max. Power 300W

Specifications

sunpower pv solar panel module system
We are engaged in the designing producing solar module, hope we can give you best support

sunpower pv solar panel module system

lsunpower pv solar panel module system

  • Designed according to and complying with all requirements in IEC 61730 and IEC 61215 ed2(Certified by TUV Rheinland )
  • White tempered glass, EVA, weather-proof substrate film and anodized aluminium frame provide adequate protection against various environmental conditions
  • The junction box and connectors with IP65 protection degree provide convenient and reliable electric connection the incorporated schottky bypass diodes protect the module from hot spot damages
  • Cells are 100% visually inspected and sorted according to electric characteristics against mismatching
  • Visual inspection, performance measurement and dielectric strength tests on every product
  • All backed by a 25 year limited power warranty (≥80%) and 2 year workmanship warranty
  • Customization upon request

We are engaged in designing, producing solar panel and system, hope can give you best support in near future.
The following is a part of our cells data
If you want to get more information please ask me feel free, my Skyp: jackhuang1232, hope we could give you best support in near future.

    Pmax

    160W

    165W

    170W

    175W

    180W

    185W

    Voc

    43.4V

    43.6V

    44.2V

    44.2V

    44.2V

    44.6V

    Isc

    5.09A

    5.10A

    5.15A

    5.25A

    5.36A

    5.60A

    Vmp

    34.5V

    35.4V

    35.6V

    35.8V

    36.2V

    37.0V

    Imp

    4.64A

    4.66A

    4.78A

    4.89A

    4.97A

    5.00A

    Tolerance

    ±3%

    Fuse rating

    10A

    Maximum system voltage

    DC1000V

    Dimension

    1582*809*50mm/1580*808*35mm

    Cell type

    125*125mm/72 mono-crystalline cells



    Net weight

    16.5KG

    Mechanical load

    5400Pa

    NOCT

    47±3°C

    Operating temperature













    sunpower pv solar panel module system
