Home Solar System Freeshipping

Name: Home Solar System Freeshipping
Brand: GH solar energy
SKU: 130618319
Availability: InStock

US$ 0.7 - 1.2 MOQ: 1000 Watts

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GH solar energy

Model Number:

GH- 8286

Zhejiang Ganghang Solar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/ Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GH solar energy

Model Number GH- 8286

Material Monocrystalline Silicon

Number of Cells 72

Max. Power 280W

Specifications

off grid solars ystem
1.Economical,safe,green
2.Super power,high efficiency
3.Top quality,low price
4.CE,ROHS,IEC

- CE, ROHS, TUV approved.

- High conversion efficiency, high-transmission rate.

- Energy saving, environmental-friendly.

- Advanced technology, strict quality control system.

- Easy installation, safe operation, free maintenance.

- Low MOQ, fast delivery time, long service life.

Solar Home System Applications:

1. Living house and home building

2. Office building, factory and warehouse

3. Shopping mall, venue, stadium and so on

4. Power station, field operation and some huge engineer construction.

Normal parameter
Mode	GS-F-6KW
Output power	6KW/every day
Working Days	3 consecutive cloudy or rainy days
Work temperature	-30°C~+60°C
Protection grade	IP 65
Use Region	This configuration is suited to use in the regions where the average daily Irradiation at the lowest average radiation month is about 3KW/m². If the average daily irradiation is higher or lower than 3KW/m², the configuration should be adjusted. We can provide efficient products according to the use region.
Power resource
Power resource	reliable PV modules(solar panel)
Cell technology	mono-crystalline or poly-crystalline silicon
the maximum power at STC	2400W
Energy storage
Energy storage	deep discharge sealed lead-acid battery
Battery number	6
Nominal voltage	12V
Rated capacity	250Ah
Protection	over charge and over discharge protection
Use life	3 years at least
Controller
Controller	Solar energy intelligent specialized controller
Control mode	switch on/off by light and time
Controller & Inverter
Controller & Inverter		Solar energy intelligent specialized Controller & Inverter
Output wave		Pure sine wave
Output voltage		AC110/220/230V
Output frequency		50HZ/60HZ
Precision of output voltage		±3%
Precision of output frequency		±0.1%
False output wave of AC		<3%
Overload ability		120%, 30 seconds
Invert efficiency		>90%

Load for example:
