SOLAR SYSTEM Solar Energy Photovoltaic

Name: SOLAR SYSTEM Solar Energy Photovoltaic
Brand: GH soler energy
SKU: 130618327
Availability: InStock

US$ 0.78 - 1.2 MOQ: 100 Watts

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

GH soler energy

Model Number:

GH-3264

Zhejiang Ganghang Solar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/ Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name GH soler energy

Model Number GH-3264

Specification Normal

Application Home

Output Voltage (V) 220

Load Power (W) 5000

Solar Power (W) 18%

Work Time (h) 12

Specifications

SOLAR SYSTEM solar energy photovoltaic
Our products bear IEC, TUV, UL, MCS, CQC, KIER, CE, PV CYCLE membership

SOLAR SYSTEM solar energy photovoltaic

1.POWERED BY SOLAR ,OUTPUT MORE THAN 5000W
2.NO POLLUTION,EASY TO OPERATE
3.LONG WORKING TIME AND HIGH EFFICIENY

ARXT5000 Solar system /house SOLAR system
1.Widely used for electricity, industry, communication, navigation, irrigation, PV house and remote power requirements
2.WE CAN ADJUST THE OUTPUT TO CUSTOMER REQUIREMENT
3.YOU CAN SET IT BOTH ON ROOF AND ON GROUND, MORE CONVENIENT
4.BOTH ON GRID AND OFF GRID SYSTEM
SPECS

Solar Cell Module	Max power	3060 W( 180W×17)
	Converting efficiency	≥ 16% poly-crystalline silicon with 125×125 standard square
	Electrical data	Open circuit voltage	44.5V	Max voltage	35.9V
		Short circuit current	92.16A	Max current	85.32A
	Type and Size	Type A	1 array*6modules in series 4948×1580 mm×3	Module size	808×1580×35 mm
		Type B	——
	Installation angle	Install at 0°~ 60°from the horizontal
Battery Pack	Rated capacity	1200AH	Combined mode	2V/1200AH (12 pieces in series)
	Rated voltage	24V
	Battery type	Maintenance-free lead-acid	Discharging rate	≤70%
	Ambient temperature	-30°C~+60°C	Weight	1840Kg
	Lifetime	10 years
Charge/discharge Controller, Input&output	Charge/Discharge controller	Model	80A
		Size	80A ( 12/24 adaptorable )
		Manufacturer	Phocos
	DC output	24V	For DC electrical tools
	AC output-A 50/60Hz	Inverted output of standard electricity wave	Rated output power 1500W for group-adaptive loads e.g.: lights, TV, electrical heaters etc.
	AC output-B 50/60Hz	inverted output of pure electricitywave	Rated output power 1500W for geist electrical machines loadse.g.:fridges,electrical fans,water pumps etc.

Max Output	DC	12V	100W	Rated output(100%)	DC	12V	60W
		24V	200W			24V	150W
	AC	Standard electricity wave	2100W		AC	Standard electricity wave	1500W
		Pure electricity wave	2100W			Pure electricity wave	1500W
Power ability for 50% loads		Available Power for a sunny day’s charge				6—8 hours
		Available power for full battery				25 hours
