130w PV Photovoltaic Panel With 36 Pcs Multi Silicon

Name: 130w PV Photovoltaic Panel With 36 Pcs Multi Silicon
Brand: Ganghang
SKU: 130616095
Availability: InStock

US$ 0.8 - 2 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Ganghang

Model Number:

GH-P-013

Zhejiang Ganghang Solar Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo/Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Ganghang

Model Number GH-P-013

Material Polycrystalline Silicon

Size 1466*676*35 mm

Number of Cells 36(4*9)

Max. Power 130W

Specifications

1.high efficiency and the suitable power
2.monocrystalline or polycrystalline
3.the photovoltaic panel could as your need

130w PV Photovoltaic Panel with 36 pcs Multi Silicon Details:

Main products: solar cell, solar panel, solar power system below 10kw etc.
MOQ: 100pcs(sample order and trial order are welcomed)
Warranty: -6month-1year for solar cells, -5years product warranty,10years 90% and 20years 85% for solar panels, -1year for solar systems
OEM order: welcomed
Certificate: CE,TUV, UL etc.
Package: wooden case
Delivery term: about 30days by sea

Parameter:

Model	GH-P-013
Pmax	130W
power tolerance:	±3%
Vmp	19.0V
Imp	6.85A
Voc	22.6V
Isc	8.24A
Pcs	36(4*9)
Cell Type	156*156 polycrystalline solar cell panel
Size	146667635 mm
Net weight	14 kg
STC	1000W/m2,AM 1.5,25oC
Warranty	3 year warranty for products,10 years for 90% power ,25 years for 80% power
Accessory	3.2mm thick tempered glass,aluminium frame
Others	There are drainage holes on the Border components, eliminating the framework of deformation caused by rain or snow accumulated in the framework
