water treatment uvDurable full ss structure
Automatic RO water treatment system
ODM available
water treatment uv
Features:
1. Automatic backwash and manual backwash
2. Automatic switch on when low water level, and switch off when high water level
3. Water shortage protection for multi-stage pump
4. Protection when no voltage, under-voltage, over-current, short circuit and creepage
5. Full stainless steel structure, durable and easy to clean.
6. Integrating water flow indicator, TDS indicator, pressure indicator, control panel
7. China Top Brand or world famous brand electrical, switch and valve systems
8. Built-in soft-start system to avoid damage to the expensive membrane when starting
9. Built-in RO membrane chemical washing device
Specification:
Parameters | |
Product |
One-stage Automatic RO(Reverse Osmosis) water treatment system |
Model |
RO-1000i(8000L/H) |
Pure Water Production Capacity |
8000 litre per hour(25°C) |
Input water quality |
TDS≤12000PPM(recommended) |
Salt Rejection Rate |
≥97% |
Recovery Rate(pure water : inlet water) |
50~75% |
Recommended Working Temp. |
5~35°C |
Input Power(standard) |
AC380V / 50Hz / 15.0KW |
Pre-treatment | |
Quartz Sand Filter |
Fiber glass tank Φ1000×1800mm×1PC including 1500KG quartz sand Or optional Φ1000×2000mm(t3.0mm) SUS304 stainless tank |
Active Carbon Filter |
Fiber glass tank Φ1000×1800mm×1PC including 500KG activated carbon Or optional Φ1000×2000mm(t3.0mm) SUS304 stainless tank |
Water softener |
Φ530×1500mm fiber glass tank with 200L food-grade resin and 180 automatic control valve(Total hardness≤300PPM) |
Micron (PP Sediment) Filter |
SUS304 tank Φ330×1000×t1.5×1PC (including 5u×1000 PP filter × 8PCS) |
Booster Pump |
China Nanfang CHL16-30 pump×1PC / 3.0KW Or optional Denmark GRUNDFOS CR15-3 pump×1PC / 3.0KW |
Multi-stage Pump |
China Nanfang CDL8-140 pump×1PC / 11.0KW Or optional Denmark GRUNDFOS CR15-12 pump×1PC / 11.0KW |
RO System | |
Membrane |
U.S. DOW FILMTEC BLACKISH Water Series BW30-400×8PCS or HYDRANAUTIC ESPA1-8040×8PCS |
Housing |
SUS304 stainless steel 4040 housing×4PCS |
Accessories | |
Piping |
U-PVC quick connection |
Structure |
Full SUS304 stainless steel 40160 housing×2PCS |
Electrical Parts |
China Tengen Or optional SIEMENS / MISTSUBISHI / ABB |
Others |
Flow metre, TDS metre, pressure metre, electromagnetic valve, etc. |
OPTIONAL |
Chemical dosing system, UV sterilizer, ozone sterilizer, and built-in RO membrane washing device |
