Specifications
Applied in weighing and loading control of trucks in construction, agriculture, forestry and waste disposal.Truck weighing system
Model: ZH180B2
Description
Based on ZH180A, ZH180B increases the size of weighing bridge. Seven steel strips are embedded in weighing bridge to strengthen the connection, so the dynamic accuracy is greatly increased. The enlarged weighing bridge enables itself to be used in more types of vehicles.
ZH180B2 can be used in vehicle overload-alarm system.
Dimensions
Specification
Rated load: |
15 t/20t |
Rated output: |
1.2/1.5±0.1mv/v |
Repeatability: |
0.05%FS |
Error on corners: |
0.2%FS |
Zero balance: |
≤1%FS |
Static comprehensive error: |
0.2~0.5%FS |
Dynamic comprehensive error: |
3%FS(1~5km/h)/ 5%FS(5~10km/h) |
Ultimate overload: |
150%FS |
Non-linearity: |
0.5%FS |
Use temp.range: |
-30~80°C |
Compensated temp.range: |
-10~50°C |
Temp.effect on span: |
0.03%FS/10°C |
Temp.effect on zero: |
0.05%FS/10°C |
Output resistance: |
2100Ω |
Defend grade: |
IP 66 |
Recommended voltage: |
10V |
Excitation voltage: |
9~15V |
Net weight: |
30kg |
Max load of 1/4 weigh bridge: |
6t/8t |
Full load: |
15t/20t |
Dimension of the surface: |
700x350mm |
Insulation resistance: |
≥5000MΩ(100VDC) |
Remark: Four-core shielded cable is attached: φ5.8x10m | |
Application and installation
