Specifications
flexbible melt pressure sensorhigh precision/proformance,competitive price
internal 80% calibration
12 months warranty
Economic flexible melt pressure sensor with mV/V output
Description
PT124G-124 Series Melt Pressure Transducer (Flexible stem) ,is widely used in both domestic and abroad.This series can be utilized together with the N Series Intelligent Digital Pressure Instrument. Zero & full span can be adjustable, PT124G-124 welding with amplify circuit can be change to PT124B-124 , the signal be connected with PLC directly , with advantages of high precision and reliable pressure measuring and good quality and internal 80% calibration. international standard , can replace Dynisco ,Gefran ,GP50 absolutely .
Feature
Stainless steel welding,Easy to install
Zero and span adjustable
Various amplified signals optional
Internal 80% shunt calibration
Good stability and anti-jamming capability
Excellent stability and repeatability
can replace Dynisco ,Gefran ,GP50 absolutely .
Application
Chemical fiber Equipment
Plastic and Rubber manufacturing equipment
Medicine & Food process equipment
Measurement and Control all kinds of melt fluid
Specifications
Name |
Economic flexible melt pressure sensor with mV/V output |
Model |
PT124G-124 |
Pressure range |
0-3.5MPa…0-150MPa (0-500psi…20000psi) |
Over Pressure |
1.5 X FSO |
Combined Error |
± 1.0% FSO; ±0.5% FSO (Including Linearity, Repeatability & Hysteresis) |
Output |
3.33 mV/V, 2mV/V |
Input Voltage |
10VDC |
Repeatability |
+/- 0.2%FSO |
Bridge Resistance Input |
345 Ohms minimum |
Bridge Resistance Output |
350 Ohms +/- 10% |
Internal Shunt Calibration (R-Cal) |
80% FSO +/- 1% |
Insulation Resistance |
200 megohms @ 100 Vdc |
Max Diaphragm Temperature |
400°C |
Mounting Torque |
500 inch/lbs. max. |
Standard Wetted Parts |
Diaphragm coated 15-5 PH SST |
Electrical connector |
5PIN, 6PIN connector |
Process connector |
M22*1.5 , M14×1.5, M18×1.5 Optional |
Drawing:
Order Guide : with "* "are required , with "---"is optional
Model |
Range |
output |
Rigid & flexible length (inch) |
Screw Thread |
Electric connector |
Accuracy |
others |
PT124G-124 |
* |
* |
* |
* |
* |
* |
--- |
Example:PT124G-124-30MPa-2mV/V -6/18”-M14*1.5-5PIN-0.5% |
|||||||
Price, Service and Package
1. FOB competitive price , 5-7 working days fast leading , on line service .
2. Your inquiries about our melt pressure sensor will be replyed in the shortest time.
3. All our melt pressure sensor will be fully checked by our QC before delivery.
4. all our melt pressure sensor are 7 days free replace , 12 months free repair if casue for quality problem .
5. Package: The goods will be put into the packing box with instructions and quality certificate quality first ,then we pack them into the box with polystyrene foam to avoid damage of the products.
6. Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder.
Company profile
We ZHYQ is the leading manufacture which specializes in the design and construction of various transducer, transmitter and automation control products for more than 15+ years. Our main products contain melt pressure transmitter, melt pressure transmitter, melt pressure sensor , automotive pressure sensors, pressure gauge, temperature transducer and pressure instrumentations, etc. We service the markets of Industrial, Oil & Gas, Automation Control System, Plastics, Rubber, Composites , etc.
With the development strategy of offering High-tech, High Quality, High level service to every customer, we successfully passed ISO9001 (2000) and CE Certificates. What’s more, our products are highly welcomed in Asia, America, Europe, Africa and many other countries.
Your requirement is our creating power; your satisfaction is the greatest reward and confirmation to us. And we’ll make persistent efforts to improve our technology and service to meet your needs!
