Specifications
shear beam load cell1.high stability load cell
2.welding
3.alloy steel structure
4.CE&ISO9000 certified
Truck scales shear beam load cell sensor
Description
1,material:alloy steel
2,shear beam
3,cost effective
4,high capacity
5,high precision
6, welding
Application
Electronic platform scales, track scales, etc.
Parameters
Rated Load(t) |
0.5,1,1.5,2,2.5,3,5 |
|||
Precision |
C2 |
C3 |
Insulation Resistance(MΩ) |
≥5000(100VDC) |
Comprehensive Error(%F.S) |
0.03 |
0.02 |
Excitation Voltage(V) |
9~12(DC) |
Rated output(mv/v) |
3.0±0.003 |
Compensated temp.Range(°C ) |
-10~+40 |
|
Non-linearity(%F.S) |
0.03 |
0.02 |
Use Temp. Range(°C ) |
-20~+55 |
Hysteresis(%F.S) |
0.03 |
0.02 |
Temp.Effect on Zero(%F.S/10°C) |
0.02 |
Repeatability(%F.S) |
0.02 |
0.01 |
Temp.Effect on Span(%F.S/10°C) |
0.02 |
Creep(%F.S/30min) |
0.03 |
0.02 |
Safe Overload (%F.S) |
150 |
Zero Balance(%F.S) |
±1 |
Ultimate Overload(%F.S) ) |
200 |
|
Input Resistance(Ω) |
350±3 |
Defend Grade |
IP67/IP68 |
|
Output Resistance(Ω ) |
350±10 |
Cable (4PIN) |
RVVP4*12/0.15*3m |
|
Dimensions
