Digital Pressure Instruments with relay alarms output
- 6000 Piece / Pieces per Month
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
- laser distance meter PD38
- HANDHELD LASER DISTANCE METER,HANDHELD RANGE FINDER, DISTANCE METER,PD23,40M
- HANDHELD LASER DISTANCE METER,HANDHELD RANGE FINDER, DISTANCE METER,PD54,40M
- HANDHELD LASER DISTANCE METER,HANDHELD RANGE FINDER, DISTANCE METER,PD56,60M
- Laser Range Finder PD58
- laser distance meter HP800
Product Details
Place of Origin: | Shanghai, China | Brand Name: | ZHYQ | Model Number: | N70 |
Product Description
Specifications
Digital Pressure Indicators with relay alarms outputAnti- jamming
can mataching with all kinds of pressure sensor's output
Digital Pressure Instruments with relay alarms output N70
Discription
N70 Digital Pressure Instruments with relay alarms output is a 1/8 DIN or ¼ DIN, panel-mount, dual 4-digit indicator, which takes the advantage of latest state-of-art technology and comes in small-size, light-weight and in low-power.
This pressure instrument has been specifically designed for use with mv/Volt output transducers from different famous manufacturers such as Dynisco, Gefran, ONEhalf20 and so on. This series indicator can match ZHYQ’s melt pressure transducer also.
Application
N70 Pressure instrument can be widely used in situation of display and autocontrol in Hydraulic pressure, oil, plastics, latex, printing and dyeing, textile industry; AND also can be compound with resistance strain guage press sensor of other manufactory
Specification
(1) | Display | Dual 4-digit Green and Red LEDs |
(2) | Resolution | 0.2% FSO ± 1 |
(3) | LEDs | Out, Alarm-1, Alarm-2, CALibration |
(4) | Input Sensibility | 2.5mv/V or 3.3 mv/V (automatic selection) |
(5) | Sampling Speed | 20 per second |
(6) | Excitation Voltage | +9 VDC (output to transducer) |
(7) | All Output Relays | Relay 220V 1A |
(8) | Retransmission | 4~~20 mA standard current loop |
(9) | Communication | RS-485 MODBUS( PY500 Only) |
(10) | Alarm Range | 0001 – 9999 PSI or Bar (configurable) |
(11) | Temperature | 0 - 55°C |
(12) | Humidity | <= 80% RH |
(13) | Calibration | 80% FSO (Full Scale Output) |
(14) | Power Supply | 110/220VAC or +24VDC (designated while purchasing) |
(15) | Size | 96mm x 96mm x 100 mm (W x H x D) |
(16) | Panel Cutout | 92mm x 92mm |
(17) | Weight | 400(Maximum) grams |
Panel Dimensions
Remarks : this pressure instrument standard input is 2mV/V , output is 2 relay alarms , if you need special input or output (3.33mV/V,4-20mA ,0-5V ,0-10V) , when order it , please mention it .
Order Guide :with "* "are required , with "---"is optional
Maintenance
The operating temperature of N70 pressure instrument is 0-55°C, the relative humidity is no more than 80% RH, it can be used in the conditions without dirt or corrosive gas. It can be free repaired in 12 months from leaving our company. If there is something wrong with the use of customer or the beyond the maintenance, we should charge for the service of repair.
Price, Package and Service
1, T/T, Western Union, MoneyGram
2, Any questions from you about our pressure instrument are welcome and will be replied in 24 hours.
3, all our pressure instrument are 7 days replacement and 12 months repair free of charge for quality problem.
4, All our pressure instrument will be fully checked by our QC.
5, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder.
6. Package: 1 pcs pressure instrument / inner box , Standard export packing .
