Specifications
the extruder machine1.screw LD ratio 33:1
2.output 180-220kgh.
3.die head width 700mm.
4.sheet thickness: 0.2-3mm.
Technical Parameters:
1.It is composed of extruder, three-roller calender, traction,rewinding and electric control box.
2.The screw, material barrel, screenchanger, measurement pump, die head are made of high quality alloy steel (38CRMOAIA) with high hardness, strong corrosion resistance and long operating life after nitrogen treatment.
3.The die head adopts hanger-type branch pipe decreasing-style construction, so the flow passage is convenient for material solution to flow without stagnation and the thickness of products will be smooth and even.
4.Insiede the calender the helical flume and cycle water cooling bring a perfect cooling effect.
5.The temperatures of die head, screen changer the measurement pump and the material barrel are separately controlled.
6.All drive system runs synchronously.
Diameter Of Screw |
φ120 |
Adjust Distance Of Calender |
0-50 mm |
Adjust Distance Of Die Head |
0-3 mm |
Diameter Of Roller |
400 mm |
Width Of The Die Head |
700 mm |
Max. Output |
250kg |
Length Of Roller |
1000 mm |
Diameter Ratio |
33:1 |
Power Of Material Barrel |
42 kw |
Power Of Extruder |
75 kw |
Power Of Screw Changer |
5 kw |
Heating Power Of Die Head |
22 kw |
Air Consumption |
0.4 Mpa |
Sheet Thickness |
0.2-2 mm |
Sheet Width |
650-680 mm |
Water Consumption |
30 m3/h |
Motor Power Of Rewinding |
2.2 kw
|
Power Of Mesurement Pump |
5.5 kw |
