500W Low Frequency Solar Inverter

500W Low Frequency Solar Inverter thumbnail-1
500W Low Frequency Solar Inverter thumbnail-2
500W Low Frequency Solar Inverter photo-1
500W Low Frequency Solar Inverter photo-2
US$ 108 - 168 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
GT
Model Number:
GTP-500L
Contact Supplier Request Quote Chat Now
Zhangjiagang Great-Trust Import & Export Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name GT
Model Number GTP-500L
Output Power 500 - 1000W
Output Type Single
Size 320*145*235mm
Weight 9kg
Input Voltage 12VDC
Output Voltage 100/110/120/220/230/240VAC±1%
Type DC/AC Inverters
Output Frequency 50Hz/60Hz
Output Current 41.7A
Product Description



500W Low Frequency Solar Inverter

500W Low Frequency Solar Inverter







1. Introduction



The Solar Inverter is small, intelligent and high efficiency. In inverter state, it is almost no noise and inverter voltage is fully sine wave output, suitable for capacitive load, inductive load and nonlinear mixed load. Also, its efficiency is 10% higher than that of other inverters; protection functions are perfect, such as overload, short circuit, battery voltage over high or over low, these will not cause your machine breakdown. By RS232 communication port, the inverter and power status could be monitored from the connected PC, to understand the working data, setting inverter off, monitoring the working parameters, and to expand functionality for remote network monitoring (via SNMP ADAPTER). It can meet a variety of solar power systems.



2. Features

²  Intelligent CPU control

²  Efficient inverter technology design

²  Automatic stable voltage output

²  Over high or over low voltage input & output protection

²  230VAC50HZ automatically detect the output conversion

²  RS232 communication monitoring interface

²  INTERNET-FAX-MODEM-ADSL line surge lighting protection

²  Wide input voltage

²  Overload/ over temperature output protection

²  LED light/LCD display and alarm buzzer

²  SMT technology

²  Light designed, beautiful and durable



3. Optional Functions

1.Remote Control(RMON): SNMP interface

2. Bypass function: AC grid or generator supply power

3. AC charger current: 1-20A   (Recommended Battery Type: Lead acid)

4. Solar charge controller: 10A-60A (PWM or MPPT)  (Recommended Battery Type: Lead acid)



4. Product Appearance (Front and back shown)

500W Low Frequency Solar Inverter

500W Low Frequency Solar Inverter



5. Parameters

Model

GTP-500L

INVERTER

Continuous power

520W

Surge power

1040W

DC voltage

12VDC

Power factor

0.8

Wave form

Pure Sine wave

Max efficiency

≥90% (full load)

AC input voltage range

145V~275VAC

Output AC voltage

100/110/120/220/230/240VAC±1%

frequency

50/60HZ±1%

THD

≤3%

Bat .Polarity Reverse

Fuse burn out

Bypass function

YES

AC/Inverter conversion

Slow start (output voltage from small to large for 3 seconds)

Monitoring interface

RS232 Communication interface

Man-machine interface

LCD/LED(Optional)

PROTECTION

Low battery volt

Yes, alarm every 4 second, then emergency alarm. then switch to bypass or shut down.

Over load

120% overload issue emergency alarms for 30 seconds, 125% overload issue emergency alarms for 10 seconds, and then turn off; 150% overload instant off. (automatic return to the normal state after decreasing loads )

Inverter failed

Yes, continuous alarm

ENVIRONMENT

Ambient temperature

0—50°C

Humidity

20—90% noncondensing

Noise

≤40DBA(for 1 meter distance)

Protection Class

IP 20

GENERAL

Net weight

9kg

Machine Size

320*145*235mm

Gross weight

11kg

Package Size

390*210*280mm

OPTIONAL EXTRA FUNCTION

Remote Control(RMON)

SNMP interface

Bypass function

AC grid or generator supply power

AC charger current

1-20A   (Recommended Battery Type: Lead acid)

Solar charge controller

10A-60A (PWM or MPPT)  (Recommended Battery Type: Lead acid)

Communicate surface

RS232



Packaging & Shipping



Packing:Carton box and free accessories.

Shipping :
1. FedEx/DHL/UPS/TNT for samples, Door-to-Door;
2. By Air or by Sea for batch goods, for FCL; Airport/ Port receiving;
3. Customers specifying freight forwarders or negotiable shipping methods!
4. Delivery Time: 5workdays for samples; 15 workdays for batch goods.
500W Low Frequency Solar Inverter
