Yellow-green Brightness Water Rescue Rope

carton

RESCUE LIGHTING ROPE Model

KPT-F100

Application Field

   Traffic Safety sign and guidance;
   Exit passage and stairway guidance;
   Temporary Outdoor Dangerous Area Warning;
   Float at surface/Marketplace/Subway/Coal Mine etc.
   underground place rescue;
   Surface rescue or Ship or under water guidance;
   Division of large scale gathering people;
   Field or Sky indication rescue,
   Fire/Earthquake/Flood rescue

CHARACTERISTIC

   Easy to be used, Energy-saving, To be pulled or reeled in while lighting , Continue lighting for 5 hrs, Twinkle lighting for 7hrs, To be charged by car power( with connecting wire) and appliance power .   Float at surface .

   Light is peaceful and colorful, visibility distance is about 50m.

   CE and RoHs approved, Energy saving, Environmentally friendly, No harm and danger to human body and plant and no heat radiation.

   Operate easily, our lead wire is soft and flexible, can bend, cut and connect freely.

Technical Data

   Diameter:                   12.0mm,    (PT)
   Lighting Color:             Blue green,
   Observation Distance:100 M,
   Maximum Resist Pull: 500 KGS,
  Brightness:                  1-10Cd/m2 ,
  Working Currency:      5mA/m,
  Isolated Voltage:       Over 4000V,
  Power Supply:          DC12V,
  Power :                         35w,
  Working Frequency:    1500Hz,
  Life-span:                    1000 hrs,
  Charge application Times: 500 times,
  Weight:                        25 kgs,
  Working time for full electricity: 5 hrs,

Application Method

  Taking out the EL wire wheel;
  Turn on the switch to judge if there is power or not,On-off-Twinkle
  Under the condition of lighting, EL wire can be pulled or reeled in.
  To fix EL wire, Plastic binding strip can be used and removed repeatedly.
  Rotate the handle to reel the EL wire in neatly for easy pulling next time.

  Three Modes of Charging

To turn off the switch before charging.
1)To connect AC220V/110V charger, suggest to charge for 9hrs for fully loading.
2)Car DC12V charge: Launch car but do not step on accelerator peda, connect lead wire with car electrical Source Plug, then connect to Car power. To continue charge for half an hour and reach 50% electricity load. And cut off the connecting wire while not charging to avoid discharging.

Equipment Accessories

1 PC of 150 M EL wire wheel  (60X55X40cm);
1 pc of AC220V/110V charger;
1 pc of 5 M connecting lead wire;
1 pc of Car electrical source plug;
1 bag of Plastic Binding Strip    (20 pcs)

Repair and Maintanace

1.Do not suggest to cut and connect the EL wire.
   Use scissor to cut KPT EL wire quickly and seal the end (Photo2-3);and connect it with Electrical wire (Photo 4-7);

2.Construction:
   Inner EL wire wheel:Inverter; Electricity power; Switch;
   Outside EL wire wheel:Switch, Charger, Handle, Steel tube frame, Wheel;
   Lighting Rope:KPT EL wire core(grey color),Glow-in-dark Core(Green),PVC(Transparent);
   Lighting rope working Voltage for : AC120V,1500Hz;
3.Keeping Methods:
  To keep it in Aluminum Box with 10-30 Celsius degree after full charging ,and check it each 30 days.
4. Replacement of Lighting rope
   The end of lighting rope connects with power  with a water proof connector and the lighting rope can be replaced .

Remarks

1.EL wire wheel can not be used in rain ,as no anti water protection for electricity control parts.

2. Do not launch engine as bigger currency will damage electrical controller when connecting to DC12V car power;

3.EL wire will not work well such as emit heat, light not continuously or have short circuit if bending angle is less than 45 degree or pulling strength is beyond required resist pull;

4.Pls. do not remove end parts or inner equipments to avoid the invalidation of anti water ability and change of resist pull.

5. Temperature for battery working and keeping is from -10 to +50 Celsius Degree ,otherwise will damage electrical circuit or discharge or explosion
