Recycled Paper Pencil Making Machines / Lead Pencil Machine
Recycled Paper Pencil Making Machines / Paper pencil rolling machine / pencil making production line / selling waster paper pencil making machine
Advantage of paper pencil making machine :
1, state support environmental protection industry
2, cost less than wooden pencils
3, performance was better than wooden pencils
4, the production process is simple
Introduction of paper pencil making machine :
the latest generation of series of paper pencil equipment, with the most advanced level,
improve and streamline the production process, automatic coating film shot machine, fully
automatic coating cycle, a computer for 8 hours can pen 18000 - 20000 volumes, provincial
working hours, the volume bar effect; no pollution, no huge investment in the end,
non-timber can not produce the history of pencils, wooden pencils factory investment
business and the ideal equipment for changing products .
production process:
paper cutter → rolling machine →drying → cutting and polishing → shrinking machine→
eraser
Mahchine details of paper pencil production line :
1. Paper cutting machine :
This machine is to cut the 18*56cm newspapers into pieces for further processing.
Max thickness of paper: 40mm
Max length of paper: 750mm
Weight: 100kg
Dimension: 1200*1000*900
2. Pencil stick rolling machine
This machine used to roll the pieces of newspaper into pencil sticks.
When rolling, you need glue.
Productivity: 80pcs/min
Motor: 220V 1.5kw
Weight: 140kg
Dimension: 1900*450*1300mm
3. Pencil sticks drying machine :
This machine is to dry the pencil sticks.
Productivity: 4000pcs/time
Motor: 220V 2.2kw
Weight: 70kg
Dimension: 760*550*680mm
4.Pencil cutting and polishing machine all in one machine
This machine used to cut and polish the dry pencil sticks
Capacity: 100pcs/min
Motor: 220V 1.7kw
Total weight: 130kg
Dimension: 900*450*1150mm
5. Shrink packing machine :
This machine used to pack the pencils in colorful plastic papers.
Capacity: 100pcs/min
Power:220v 1.5kw
Weight: 60 kg Dimension: 1160*430*780mm
6. Pencil heading machine
This machine is to head the eraser.
Parameters
Capacity: 30 pieces/min
Weight: 10 kg
Dimension: 600*450*1000mm
7.Packing pictures:
8. Finished product
