63kw Heat Recovery Air Cooled Modular Water Chiller
US$ 5,000 - 500,000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Type:
Air-Cooled
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
FOSHAN CHINA
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Industrial Air Source Heat Pump Hot Water Heater 52kwUS$ 5,000 - 13,000MOQ: 1 Unit -
All in One Heat Pump for Family, Home Heat PumpUS$ 900 - 1,100MOQ: 1 Set
-
T3 Industrial Air Water Cooled ChillerUS$ 1,000 - 15,000MOQ: 1 Unit
-
Modular Air Cooled Water Chiller, Heat Recovery Unit 32kwUS$ 5,000 - 500,000MOQ: 1 Unit
-
High Temperature Heat PumpUS$ 30,000 - 35,000MOQ: 5 Units
Condition
New
Type
Air-Cooled
Place of Origin
Guangdong, China
Brand Name
ASEAIR
Model Number
ACWH-063K1H
Cooling Capability(kw)
63kw
Voltage
380V-3phase-50Hz
Dimension(L*W*H)
2070X950X1900mm
Weight
780kg
Certification
CE, ROHS
Warranty
2 years
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
63kw air cooled modular chiller, heat pump, with heat recovery, recover heat to produce free hot water, 30 to 1000kwModular air water heat pump, air cooled modular water chiller with heat recovery unit.
1) recover thermal energy to produce free hot water.
2) ideal solution for providing cooling, heating, hot water for commercial building like Hotel, plaza, office
building etc.
3) Provide full technical support for project design, solution. FREE SERVICE.
4) 2 years warranty.
Technical data sheet
| |
cooling only | ACW-032K1H | ACW-063K1H | ACW-095K1H | |||||
| Heat Pump | ACWH-032K1H | ACWH-063K1H | ACWH-095K1H | ||||||
| Air Conditioning | Cooling Capacity | kw | 31.5 | 63 | 94.5 | ||||
| 10000kcal/h | 2.71 | 5.42 | 8.13 | ||||||
| Heating Capacity | kW | 34 | 68 | 102 | |||||
| 10000kcal/h | 2.92 | 5.85 | 8.77 | ||||||
| Power Source | 380V/3PH/50Hz | 380V/3PH/50Hz | 380V/3PH/50Hz | ||||||
| Ambient Operating Temp. | °C | Cooling: 17°C~46°C; Heating: -10°C~21°C | |||||||
| Noise Level | dB(A) | 64 | 68 | 69 | |||||
| Refrigeration System | Compressor | Type | Full Enclosed Scroll | ||||||
| Quantity | 2 | 4 | 3 | ||||||
| Rated Power Input | kw | 5.0x2 | 5.0x4 | 10x3 | |||||
| Refrigerant | Type | R407c | R407c | R407c | |||||
| Charging Volume | kg | 4.6x2 | 4.6x4 | 8.3x3 | |||||
| Air-side Heat Exchanger | Type | V-shaped Fin-Tube | |||||||
| Fan Type | Axial Fan | ||||||||
| Fan Quantity | 2 | 2 | 3 | ||||||
| Fan Power | kW | 0.37x2 | 0.75x2 | 0.75x3 | |||||
| Water-side Heat Exchanger | Type | High-efficiency Shell-Tube | |||||||
| Water Flow | m3/h | 5.4 | 10.8 | 16.3 | |||||
| Water Pressure Drop | kPa | 37 | 38 | 40 | |||||
| Max. Bearing Pressure | MPa | 1.0MPa | 1.0MPa | 1.0MPa | |||||
| Pipe Size | mm | DN50 | DN50 | DN65 | |||||
| Heat recovery for domestic hot water production | heat recovery cap | kw | 6.3 | 12.3 | 18.9 | ||||
| Type | High-efficiency Shell-Tube | ||||||||
| Water Flow | m3/h | 1.1 | 2.2 | 3.3 | |||||
| Water Pressure Drop | kPa | 24 | 24 | 24 | |||||
| Max. Bearing Pressure | MPa | 1.0MPa | 1.0MPa | 1.0MPa | |||||
| Pipe Size | mm | DN25 | DN25 | DN25 | |||||
| Expansion | Capillary | Capillary | Capillary | ||||||
| Modular Quantity | unit | 1 | 1 | 1 | |||||
| size | W | mm | 2070 | 2070 | 2933 | ||||
| D | mm | 950 | 950 | 950 | |||||
| H | mm | 1900 | 1900 | 1900 | |||||
| Weight | kg | 590 | 780 | 780 | |||||
| Optional electrical element | PTC | PTC | PTC | ||||||
| Water System Installation | |||||||||
| Remarks: | |||||||||
| 1, Rated Cooling Condition: environmental air temperature(air source) dry bulb temperature 35°C, | |||||||||
| return water temperature 12°C, delivery chilled water temperature 7°C. | |||||||||
| 2, Rated Heating Condition: environmental air temperature(air source) dry bulb temperature 7°C, | |||||||||
| wet bulb temperature 6°C, return water temperature 40°C, delivery heated water temperature 45°C. | |||||||||
| 3, Heat Recovery at Cooling: domestic hot water delivery temperature 45~55°C, | |||||||||
| return water temperature 12°C, delivery chilled water temperature 7°C. | |||||||||
Hydraulic diagram
