Automatic High Speed Side-fold Dispenser Napkin Machine.
Model No. |
LNM-2L |
Output type |
2 line output 1line more lines output available. |
Folding speed |
500-700 piece/min/line x 2lines, depending on the paper quality and napkin size. |
Raw paper |
13-20g/m2 2-ply, 20-45g/m2 1-ply, wooden pulp paper or others. Other sizes please specify. |
Jumbo roll size |
≤ 340mm x Φ1200mm (Depending on your napkin size, or customized) |
Napkin unfolded size |
170x170mm. Other size can be Customized. |
Napkin folded size |
85x120mm. One size is fixed. One napkin size is adjustable, decided by the paper roll width. |
Folding type |
Vacuum folding and 1/4 fold. Other folding types available. |
Folding unit |
With folding fingers. With web tension control system. |
Embossing unit |
1- Steel to paper(wool), Male to female. (Steel to steel is available.) 2- Embossing pattern can be any LOGO, brand name, flowers etc. 3- Embossing pattern can be customized by client or recommended by us 4- Controlled by screws, mechanical pressing type. Cylinder type is optional. 5-NEW Embossing Technology available, to be discussed further. |
Printing unit |
1- Flexo printing type. 2- Printing colors customized up to 4 colors. 3- Printing Logo is changeable. You just need to change the Printing Rubber only. 4- Annilox printing roll for printing. 5- Printing roll is adjustable flexibly. |
Tension control |
Speedless Tension control unit to fit the machine for paper of different quaity and different gsm. |
Calendar unit |
Make the napkin softer and better for printing. |
Counting |
Automatic counting unit |
Emergent stop |
Emergent stop unit to inspect any paper breaks, paper jams. |
Paper feeding |
Synchronizer for feeding paper Automatic loading jumbo rolls. |
Power |
5Kw (3-phase AC380V 50Hz or customized) |
Machine size |
6x2x2m. |
Weight |
3000KG |
| Videos and photos available. | |
Below are photos of our Automatic High Speed Side-fold Dispenser Napkin Machine. for your reference.
Overview of our Automatic High Speed Side-fold Dispenser Napkin Machine.
Our Automatic High Speed Side-fold Dispenser Napkin Machine can be with 1 or 2 lines output production or more, with perfect folding.
Perfect folding even the machine is running at 700 piece/min/line of our Automatic High Speed Side-fold Dispenser Napkin Machine.
Below are embossing patterns made by the NEW Embossing Technology of Automatic High Speed Side-fold Dispenser Napkin Machine.
The embossing patterns made by the NEW Embossing Technology of Automatic High Speed Side-fold Dispenser Napkin Machine looks very attractive.
Colors printed Dispenser Napkins Brown Kraft or White produced by our Automatic High Speed Side-fold Dispenser Napkin Machine.
White Dispenser Napkins with color printing produced by our Automatic High Speed Side-fold Dispenser Napkin Machine.
Brown Dispenser Napkins without color printing made by our Automatic High Speed Side-fold Dispenser Napkin Machine. Standard is steel to paper. Other types are optional.
White Dispenser Napkins without Color Printing made y our Automatic High Speed Side-fold Dispenser Napkin Machine.
Folding type 1/4 folded Dispenser Napkins produced by our Automatic High Speed Side-fold Dispenser Napkin Machine . Normally for 1/4 folding type, unfolded size is 170x1700mm and folded size is 85x120mm, as shown below. Other sizes can be customized.
Perfect folding of 1/4 folded Dispenser Napkins made by our Automatic High Speed Side-fold Dispenser Napkin Machine.
Folding type another 1/6 fold Dispenser Napkins made by our Automatic High Speed Side-fold Dispenser Napkin Machine.
Folding type other folding Dispenser Napkins can be made by Automatic High Speed Side-fold Dispenser Napkin Machine.
Finished Color Printed Dispenser Napkins put in the box made by our Sytem Automatic High Speed Side-fold Dispenser Napkin Machine.
Finished plain Dispenser Napkins put in the box made by our Automatic High Speed Side-fold Dispenser Napkin Machine.
