Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
Technical parameters of Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
Type |
DNM-2L |
| Output |
2lines output. 1lines, 3lines and 4lines output available and customized. |
| Speed | 300-400 sheet/min/line x 2lines |
Raw material |
13-18g/m2 2-ply virgin tissue; 18-35g/m2 single ply tissue and others |
Jumbo roll size |
≤ 660mm x Φ 1200mm (Width x Diameter) Or to be customized. |
Unfolded size |
330x330mm±2mm (Other sizes 330x330mm, 430x380mm available.please specify your size) |
Folded size |
165x82.5mm±2mm |
Folding type |
1/8 fold, 1/6 fold, 1/4 fold, L shape folding and other special folds. Vacuum folding; |
Control |
Inverter control Emergency stop Automatic stop if paper breaks or used up. JOG Stepless adjusting speed |
Auto count |
1—999 sheets |
Embossing |
steel to paper embossing. Any LOGO, words etc. steel to steel optional NEW Embossing Technology available, to be discussed further. |
|
Printing
|
2 colors printing units. (flexo printing and changeable printing pattern) |
Cluster ink net grain roller | |
Printing roller can be adjusted | |
Printing contraposition setting | |
In-phase belt, gear drive | |
Stainless steel | |
Back stand |
Strong steel configuration |
One back stand | |
Power |
AC380V 50HZ or 220V 60HZ or customized. |
Air pressure |
0.5 Mpa(buyer supply) |
| More details like photos and videos available. Please contact us. | |
Overall view of Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
2 lines Output with perfect folding of our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
Perfect folding of Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
2lines output and 2 colors printing of our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
Finished 2 colors printed dinner napkins produced by our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
Dispenser napkins with 2 colors printing made by our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine.
Our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine is with 2 colors printing units. Each printing unit can be adjusted flexibly. Each printing unit is with Doctor Blade and covers to remove the surplus ink to ensure high speed running without ink spraying out of the ink tank.
On the back side of the printing units of our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine are also with Doctor Blades to remove the ink and paper dusts.
Our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine is with steel to paper embossing unit. Steel to steel is optional. We have NEW Embossing Technology. Please contact us for more details.
The embossing patterns made by the NEW Embossing Technology of Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine looks very attractive.
Embossing patterns of our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine can be such LOGO, brand name etc. as shown as below.
Folding way of our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine is 1/8 fold, 1/6 fold etc. Other special folding also available to be customized.
Our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine can also make other special folding dispenser napkins as shown below.
Our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine can also make other special folding dispenser napkins as shown below.
Our Siemens Mitsubishi PLC controlled 2 Lanes Italy Design Embossing Printing High Speed Automatic Paper Napkin Vending Machine can also make other special folding as shown below.
* Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine Paper Napkin Vending Machine
