Double heads Woodworking 1325 CNC Router CC-1325AH2
Detailed Features:
1. Two spindles can be working synchronously as well as separately.
2. Whole machine is welded with seamless steel structure, the stability is excellent, not easy to be deformed.
3. The machine adopts gantry movement, it can process any kinds of materials freely.
4. Adopts Germany-made ball-screw on Z axis, having the character of high precision and long life-time. XY axes adopt rack and pinion transmission, having character of fast working, high efficiency and low cost.
5. Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai etc.
6. Has the function of re-carving after break point and power failure.
7. Adopting advanced DSP system with USB connection, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources.
Technical Parameter
Description |
Parameter |
X,Y Working Area |
1300*2500mm for single spindle working separately |
650*1250mm for both spindle working synchronously | |
Z Working Area |
200mm |
Table Size |
1440*3040mm |
Resolution |
0.01mm |
Lathe Structure |
Seamless welded steel structure |
X,Y Structure |
Rack and pinion transmission and linear orbit |
Z Structure |
Germany-made ball screw |
Max. Idling Speed |
35m/min |
Spindle Motor Power |
3.0KW per spindle |
Spindle Rotate Speed |
0-24000r/min |
Working Voltage |
AC380V/50Hz (optional:220V) |
Working Mode |
Stepper |
Command |
G code,HPGL,U00,mmg,plt |
Operating System |
DSP handle control system |
Diameter of Cutter |
φ3.175-φ12.7 |
Cooling Mode |
Water-cooling |
Dust-collect Function |
Yes |
Work-holding |
By clamp |
Net Weight |
1350KG |
Gross Weight |
1500KG |
Parts:
Similar model:
Smaples:
Package & Factory:
Certificates:
For any questions, please contact:
