CC-M1325A Cheap CNC Furniture Making/Carving Machine
Standard Features:
1. Whole machine is welded with seamless steel structure; the stability is excellent, not easy to be deformed. Vacuum table with 6 vacuum zones, which can adsorb different size materials.
2. Three axes adopt Taiwan HIWIN high precision linear orbit; X and Y axes adopt rack and pinion transmission, fast working, high efficiency and low cost. Z axis adopts ball screw,with high precision and long life time.
3. Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai etc.
4. Has the function of re-carving after break point and power failure. Has the function of forecasting process time.
5. Protection device to protect the wire and one emergency switch on each later plate (3 emergency switch totals):
6. Adopting Chencan brand 3.5kw air-cooling spindle make the machine have high precision, long life-time and steady working capacity.
7. Adopting advanced DSP system with USB connection, operated with the handle, convenient operation. Our engraver can completely work off-line and do not take any computer resources.
8. Closed tank chain:
9. Perfect oil-inject system makes maintenance much easier.
10. Has duct-collect function. It will clean up the carving residuum and make the operations tidier and more convenient.
11. Fumigation-free wooden case.
Applicable materials
Wood, plastic, density board, wave board, PVC, acrylic, crystal, aluminum board, light marble and other nonmetal materials and light metal materials.
Technical Specifications
Description |
CC-M1325A |
X,Y Working Area |
1300*2500mm |
Z Working Area |
200mm |
Table Size |
1400*3050mm |
Package size |
2000*3150*2100mm |
Resolution |
0.1mm |
Max. Idling Speed |
35m/min |
Spindle Motor Power |
3.5 Kw Chencan air cooling spindle |
Working Mode |
Stepper motors and YAKO drives |
Inverter |
Fulling Inverter |
Vacuum system |
Yes |
Vacuum pump |
5.5Kw water Cooling Vacuum pump |
Operating System |
DSP control system |
Lathe Structure |
Seamless welded steel structure |
X,Y Structure |
Rack and pinion transmission, |
Z Structure |
Imported high-precision Ball screw |
Rail |
Taiwan made HIWIN guiding rail |
Spindle Rotate Speed |
0-24000r/min |
Working Voltage |
AC380V/50Hz |
Command |
G code,HPGL,U00,mmg,plt |
Diameter of cutter |
φ3.175-φ12.7mm |
Manual oil-injection |
Yes |
Dust collector function |
Yes |
Package |
Wooden case |
Samples:
