Product Details
| Place of Origin | Jiangsu, China | Brand Name | HELPASS | |
| Model Number | HPS2817D |
Product Description
New Product HPS2817D Precision LCR Meter
♦ 240×128 dot-matrix graphic LCD display
♦ Friendly user's interface and easy operation
♦ Direct reading,ABS,%
♦ 2 selectable source impedance, easy to be compatible with other LCR meters
♦ Testing level monitor function
♦ Setting parameters protection function
♦ Key locked function
♦ Automatic LCZ function
Model | HPS2817D | |
Features | ||
Displayer | Large LCD | |
Display Digits | 6Digits | |
Measurement Function | ||
Measurement Parameters | Z, Cs, Cp, Rs (ESR), Rp, Ls, Lp, D (tanδ) , Q | |
Basic Accuracy | 0.1% | |
Measurement Speed(time/sec) | Slow:5 Medium:8 Fast:17 | |
Equivalent Circuit | Series , Parallel | |
Correction | Open / short circuit Zero clearing | |
Display Method | Direct reading,ABS,%,Sorting Results | |
Test signal | ||
Test Frequency | 50Hz,60Hz,100Hz,120Hz, 1kHz,10kHz, 20kHz, 40kHz, 50kHz, 100kHz (10 frequency points) | |
Test Level | 0.1 Vrms, 0.3 Vrms,1 Vrms, | |
Output Impedance | 30Ω,100Ω | |
Sorting and interfaces | ||
Beep | OFF,IN,HI,LO | |
Interface | RS-232C interface/HANDLER/USB Device/GPIB(option) | |
General Specification | ||
Working Environment | 0°C -40°C ,≤90%RH | |
Power Supply | 198V -242V(AC),47.5Hz -63Hz | |
Power Consumption | ≤30 VA | |
♦ AC power cord
♦ User's manual
♦ Testing report
♦ Warranty card and certificate
♦ Communication Cable
♦ HPS28001 Four-terminal Kelvin clip test line
Technical Service:
♦ We have professional engineers who design the test methods and test fixture for the product, debugged test equipment parameter to reach the optimal performance.
♦ We provide free technical training and offer free equipment maintenance technology.
♦ We can design special test programs and test fixture according to the customer.
We will arrange to ship your order with 3-15 working days after payment confirmed
1.Fedex/DHL/UPS:Reach most countries takes about 3-5 days
2.EMS:Reach most countries takes about 6-8 days
