PLCC6 5050 SMD LED RGB

PLCC6 5050 SMD LED RGB thumbnail-1
PLCC6 5050 SMD LED RGB photo-1
US$ 0.026 - 0.036 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
WEJ
Model Number:
WEJT505RGB-4R4B4G-2DP
Contact Supplier Request Quote Chat Now
Shenzhen Yongerjia Industry Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name WEJ
Model Number WEJT505RGB-4R4B4G-2DP
Type LED
Package Type Surface Mount
Max. Forward Voltage R:1.6V,G:3.6V,B:3.6V
Max. Reverse Voltage 5V
Max. Forward Current 100mA
Max. Reverse Current 10uA

Specifications

PLCC6 5050 SMD LED RGB
1.Package:5050/3528
2.Long Lifespan> 50000hours
3.Pb-free,RoHS,REACH compliant
4.Free sample

PLCC6 5050 SMD LED RGB





Features of 5050 SMD LED RGB:

*Low power consumption

*Long life-solid state reliability

*Available on tape and reel

*RoHS REACH compliant

*Emitted Color:RGB

*Viewing Angle:120 degree

*Compatible with SMT automatic equipment, Reflow soder and wave solder



Specification of PLCC6 5050 SMD LED RGB:

PLCC6 5050 SMD LED RGB
Product Data
Item PLCC6 5050 SMD LED RGB
Emitting Color RGB
Wavelength R:620-635nm,G:515-530nm,B:460-475nm
Luminous intensity R:350mcd,G:1000mcd,B:450mcd
Viewing angle 120 degree
Forward Current 20mA
Peak Forward Current 1000mA
Reverse Current 10uA
Forward Voltage R:2.0-2.4V,G:3.2-3.6V,B:3.2-3.6V
Reverse Voltage 5V
Chip brand Sanan-->Top brand of mainland China
Operating temperature -20~+80°C
Store temperature -40~+80°C
Operating Humidity 10%-60%RH
Store Humidity 40%-60%RH
Feature
  1. 5.0*5.0mm Surface Mount LEDs
  2. Used good raw material: Sanan chip, 99.99% pure Au gold wire, lens with silicon
  3. Color: RGB
  4. High quality,low-attenuation.
  5. High brightness,long life.
  6. Energy-saving and environmental protection.
Application
  • CCTV Camera
  • LED indoor lighting and outdoor lighting
  • LCD backlight
  • Decorative lighting
  • Auto meter LED decorative lighting



Mechanical Dimensions of 5050 SMD LED RGB:



Note:

1.All dimensions are in millimeters (mm);

2.XX is +/-0.1mm, XXX is +/-0.05mm unless otherwise noted;

3.The device has a single mounting surface, the device must be mounted according to the specifications.



Specification of PLCC6 5050 RGB LED:

PLCC6 5050 SMD LED RGBPLCC6 5050 SMD LED RGBPLCC6 5050 SMD LED RGB

 PLCC6 5050 SMD LED RGB

Intensity and color Bin limits of 5050 led rgb:

PLCC6 5050 SMD LED RGB

Packaging Dimensions Specification



PLCC6 5050 SMD LED RGB





WEJ Factory:

PLCC6 5050 SMD LED RGB



We promise:

 1. Your inquiry will be replied within 24 hours

 2. Pack the goods very well and delivery them as soon as possible

 3. Protection of your sales area, ideas of design and all your private information

 4. Get in touch with us if you have any requirements. We also produce various kinds of LED SMD, such as 3014, 2835, 3528, 5630, 5050, etc.

 5. We will try our best to solve the problems within or out of the warranty time.
