Specifications
The machine is with good quality,best price and good after-sale service.
W11s series upper roller universal rolling machine can prebending and rolling to proceed the plate, with high rolling precision,
no need to use any subsidiary equipment, less investment.
This machine is hydraulic three rollers machine, it used to roll the low carbon steel (such as Q235-B,20g,20R), and Low alloy steel to cycle shape in normal temperature.
The upper roller can be moved horizontal and level.
When cycle, to bring two lower rollers running through motor and reducer.
Because the standard height of lower roller is unchanged, it is convenience to feeding and operating.
Using environment of the machine:temperature-5~40°C;wet≤80%;Power supply: 380V±10% 50Hz
Note: When this equipment is rolling the Cone tube, it is 1/3 of the symmetric capable.
1.Max.rolling thickness 12mm
2.Max.pre-rolling thickness 10mm
3.Plate width 2000mm
4.Diameter of upper roller φ 240mm
5.Main motor 5.5KW
6.Hydraulic motor 4.0KW
7.Moving motor 1.1KW
Within 30 working days after payment.
It equip with front support material device and it is convenient to store and transport.
1.After finished the producing of the machine, we will inform the buyer to inspect the machine in the manufacture’s factory.
2.We provide some documents and foundation drawing within 7 days after contract date.
3.If need seller to guidance the installation, adjustment and trial, the seller is responsible for the charges within home, and other charges on
board should be paid by the buyer.
Zhongwei has forty years company history,it recorded the glorious development of shearing,press and rolling machine.Zhongwei is located in globals economically developed Changjiang Delta.It is east to Yellow Sea,south lean on Changjiang River,west to Ningyang and north to Yanfu,the superior geographical advantages supply the company’s development with good element.Zhongwei is bursting out of the booming energy,ranked the top 30 largest taxpayer,we won the “national high and new technology enterprise”.
Our company has participated in the Carton Fair for many times, meet ing friends from all around the world, and exported machines to the United States, India, Russia, Mexico, Vietnam and so on.
PRODUCTION CAPACITY--- LARGE-SCALE BORING AND MILLING MACHINE
FOREIGN VISITORS
OUR ACHIEVEMENTS AND CERTIFICATE
OUR PACKAGE
