QC12Y 12*3200 Hydraulic Swing Beam Shearing Machine

Name: QC12Y 12*3200 Hydraulic Swing Beam Shearing Machine
Brand: Zhongwei
SKU: 130380147
Availability: InStock

US$ 15,000 - 22,000 MOQ: 1 Set

Key Specifications

Condition:

New

Place of Origin:

Jiangsu, China

Brand Name:

Zhongwei

Jiangsu Zhongwei Heavy Industry Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHANGHAI

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Place of Origin Jiangsu, China

Brand Name Zhongwei

Model Number QC12Y12*3200

Voltage 380V/50HZ/3PH

Rated Power 18.5KW

Certification CE

Warranty ONE YEAR

After-sales Service Provided Engineers available to service machinery overseas

Specifications

The machine is with good quality,best price and good after-sale service.

Product Description

Hydraulic drive,swing beam,return of knife is smooth and prompt by accumulator nitrogen cylinder.

Possessing a speed blades gap adjusting device,permit to adjust steplessly the blades gap.

The stroke and frequency of shearing can be controlled.The machine has the fuction of single shearing and automatic continuous shearing.

After inputting precomputed data,the back gauge can be automatically moved,positioned and stopped.

The vertical gripper of intellect position is controlled by pneumatic system.

Steel plate welded construction ,hydraulic drive ,nitrogen cylinder return.

Convenient operation ,reliable performance and beautiful appearance.

Blade gap adjustment has the instruction board to display.The adjustment is convenient and quick.

It has the lighting device and can adjust the travel volume of the up shaft to any extent.

Working aera has the fence type personal safety protection devices.

Back gauge size and cutting times both have the digital display device.

No	Name		Data	Unit	Remarks
1	Max thickness of cutting plate		12	mm
2	Max width of cutting plate		3200	mm
3	Strength of cutting plate		450	N/mm2
4	Cutting angle		1°40′
5	Number of stroke		12	min-1
6	The distance of two columns		3240	mm
7	Length of blade		3075	mm
8	The height of working table		830	mm
9	Main motor	Type	Y160M-4		B5
		Power	18.5	kW
		Speed	1460	r/min
10	Backgauge motor	Type	Y80M2-6
		power	0.55	kW
		Speed	900	r/min
11	Axial pump	Type	40MCY14-1B
		Speed	40	L / min
		Pressure	31.5	MPa
12	Outside size	Length	3550	mm
		Width	1900	mm
		Height	1800	mm
