Help CenterQC12Y 12x6000 Hydraulic Swing Beam Shearing Machine
Related Products
-
QC12Y 20*2500 Hydraulic Swing Beam Shearing MachineUS$ 100 - 100,000MOQ: 1 Set -
QC11Y Hydraulic Guillotine Shearing MachineUS$ 8,000 - 15,000MOQ: 1 Unit
-
Hydraulic Guillotine Shear QC11Y-16X32500US$ 16,000 - 20,000MOQ: 1 Set
-
QC11Y Series Hydraulic Metal Guillotine ShearUS$ 10,000 - 30,000MOQ: 1 Set
-
QC11Y-12*2500 Hydraulic Plate CutterUS$ 12,000 - 15,000MOQ: 1 Set
Specifications
The machine is with good quality,best price and good after-sale service.
Hydraulic drive,swing beam,return of knife is smooth and prompt by accumulator nitrogen cylinder.
Possessing a speed blades gap adjusting device,permit to adjust steplessly the blades gap.
The stroke and frequency of shearing can be controlled.The machine has the fuction of single shearing and automatic continuous shearing.
After inputting precomputed data,the back gauge can be automatically moved,positioned and stopped.
The vertical gripper of intellect position is controlled by pneumatic system.
Steel plate welded construction ,hydraulic drive ,nitrogen cylinder return.
Convenient operation ,reliable performance and beautiful appearance.
Blade gap adjustment has the instruction board to display.The adjustment is convenient and quick.
It has the lighting device and can adjust the travel volume of the up shaft to any extent.
Working aera has the fence type personal safety protection devices.
Back gauge size and cutting times both have the digital display device.
No |
Name |
Data |
Unit |
|
|
1 |
Max thickness of cutting plate |
16 |
mm |
||
2 |
Max width of cutting plate |
2500 |
mm |
||
3 |
Strength of cutting plate |
450 |
N/mm2 |
||
4 |
Cutting angle |
2°20′ |
|||
5 |
Number of stroke |
12 |
min-1 |
||
6 |
The distance of two columns |
2765 |
mm |
||
7 |
Length of blade |
2600 |
mm |
||
8 |
The height of working table |
815 |
mm |
||
|
9 |
Main motor |
Type |
Y200L2-6 |
B5 |
|
Power |
22 |
kW |
|||
Speed |
960 |
r/min |
|||
|
10 |
Backgauge motor |
Type |
Y80M2-6 |
||
power |
0.55 |
kW |
|||
Speed |
900 |
r/min |
|||
|
11 |
Axial pump |
Type |
63MCY14-1B |
||
Speed |
63 |
L / min |
|||
Pressure |
31.5 |
MPa |
|||
|
12 |
Outside size |
Length |
3200 |
mm |
|
Width |
2100 |
mm |
|||
Height |
1930 |
mm |
|||
Within 30 working days after payment.
It equip with front support material device and it is convenient to store and transport.
1.After finished the producing of the machine, we will inform the buyer to inspect the machine in the manufacture’s factory.
2.We provide some documents and foundation drawing within 7 days after contract date.
3.If need seller to guidance the installation, adjustment and trial, the seller is responsible for the charges within home, and other charges on board should be paid by the buyer.
Zhongwei has forty years company history,it recorded the glorious development of shearing,press and rolling machine.Zhongwei is located in globals economically developed Changjiang Delta.It is east to Yellow Sea,south lean on Changjiang River,west to Ningyang and north to Yanfu,the superior geographical advantages supply the company’s development with good element.Zhongwei is bursting out of the booming energy,ranked the top 30 largest taxpayer,we won the “national high and new technology enterprise”.
Our company has participated in the Carton Fair for many times, meet ing friends from all around the world, and exported machines to the United States, India, Russia, Mexico, Vietnam and so on.
