Help CenterW12-40X3200 Four Roller Rolling Machine
Related Products
-
W11S-120*3000 Upper Roller Universal Rolling MachineUS$ 490,000 - 570,000MOQ: 1 Set -
W12-65X3000 Four Roller Rolling MachineUS$ 180,000 - 208,000MOQ: 1 Set
-
W11S-12*2500 Upper Roller Universal Rolling MachineUS$ 100 - 100,000MOQ: 1 Set
-
W11S-12*3000 Upper Roller Universal Rolling MachineUS$ 100 - 100,000MOQ: 1 Set
-
W11S-16*2500 Upper Roller Universal Rolling MachineUS$ 100 - 100,000MOQ: 1 Set
Specifications
This kind of rolling machine is with good quality and price, it can roll round and arc.Main technical parameter
Specification |
Unit |
W12CNC-40*3200 |
Force pressure |
kN |
5400 |
Max plate width |
mm |
3200 |
Working length of rollers |
mm |
3300 |
Max rolling thickness end |
mm |
T32*B3200(general plateσs≤245MPa) |
Max rolling central |
mm |
T40*B3200(general plateσs≤245MPa) |
Min rolling thickness |
mm |
2 |
Min rolling diameter of the min specification |
mm |
850 |
The length of remain straight flange |
mm |
About 3 times plate thickness |
Diameter of upper roller |
mm |
Φ570 |
Diameter of bottom roller |
mm |
Φ540 |
Diameter of side roller |
mm |
Φ460 |
Central angle of side rollers’ running direction and upper and lower rollers |
° |
30° |
Rolling speed |
m/min |
About 3.5 |
Main drive hydraulic pressure motor power |
kW |
55 |
Assist hydraulic pressure motor power |
kW |
22 |
Max working pressure of hydraulic pressure system |
MPa |
19.5 |
Working roller moving ways |
Hydraulic |
|
Driving way of rollers |
Hydraulic motor |
|
Number of driving roller |
2 |
|
Motor |
380V,3PH,50Hz |
