Specifications
1.WS2801 chip2.Addressable
3.RGB LED
4.5m/reel
5.2 years warranty
5050 smd rgb led strip ws2801 5VDC addressable
Features:
1. High brightness 5050 led, 32 PCS/m
2. Red, Yellow, Blue, Green, White, Warm White and RGB is available
3. Packing: 5m/reel in an anti-static package
4. Every 3-LED are cuttable for 5V strips
5. White, Black, PCB Board are available
6. Waterproof type: Silicone Tube
7. Input voltage: DC5V
Specification:
Item Modle No. |
SJ-10032-ICRGB |
Dimension |
1000mm(L)*12mm(W)*4mm(H) |
Voltage |
DC5V |
Power |
7.6W |
Color |
Pixel RGB color |
LED quantity |
32 leds per meter |
LED type |
SMD5050 |
IC style |
WS2801 |
IP Rank |
IP65~IP68(as customers' requirement) |
Beaming Angel |
120 degree |
Lumen per 1m/32LEDs |
R29/G81/B27 |
Certification |
CE and RoHS |
Lifespan |
more than 50,000 hours |
Warranty |
2 years |
Port of Shipment |
Shenzhen Yantian |
Detailed Discription:
1.This LED ribbon uses flexible PCB board as its base and adopts chip RGB as its luminous body
2.Available Color:Red,Yellow, Blue, Green, White. You can change colors with the optional controller
3.Available IC:WS2801,LPD6803,UCS1903
4.Controller:we usually select SD controller,you also could use DMX controller,DMX decoder,Arduino,Artnet
5.This product can achieve effects RGB seven colors gradual change,jumping change,etc.
6.Easy installation: Including 3M adhesive tape for convenient mounting
Product Pictures:
Applications of Waterproof 5050 LED strip :
1.Backlight or edge lighting for signage and channel letters
2.DIY lights for home use
3.Marine application and christmas decoration
4.Decorative lights for holiday, event, show, exhibition
5.Automobile and bicycle decoration
Note of Waterproof 5050 LED strip :
1.Please make LED drivers compatible with waterproof 5050 LED strip light before use LED strips
2.To use waterproof 5050 LED strip light 5M in serial, longer than 5M in parallel
3.Before use,first check the power supply used in compliance with of the power requirements
4.Each roll ask for independent power supply
How we package this product:
