144leds per Meter Ws2812B Fully Addressable LED Pixel Strip

144leds per Meter Ws2812B Fully Addressable LED Pixel Strip thumbnail-1
144leds per Meter Ws2812B Fully Addressable LED Pixel Strip photo-1
US$ 1 - 20 MOQ: 1 Meter
Key Specifications
Get Latest Price
LED Light Source:
Epistar
Type:
Flex LED Strips
Input Voltage(V):
DC5V
Contact Supplier Request Quote Chat Now
Shenzhen Centuryled Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source Epistar
Type Flex LED Strips
Input Voltage(V) DC5V
Lamp Power 34.56W
Lamp Luminous Flux(lm) R619~635/G512~528/B463~475
Color Temperature(CCT) 2800K-7200K
Working Temperature(℃) -20, 60
Working Lifetime(Hour) 50000
Certification CE
Emitting Color Other, Changeable, Pixel RGB
Place of Origin Guangdong, China
Brand Name SJ
Model Number SJ-100144-2812B

Specifications

1.144 ws2812B leds per meter
2.DC5V
3.fully addressable
4.smd 5050
5.Includes connector cables

144leds per meter ws2812B  fully addressable LED pixel strip



Features:



1)144 WS2812B leds per meter



2)1 integrated RGB LEDs per segment, individually controllable



3)5VDC power requirement



4)10mm wide self-adhesive Tape



5) over 50,000 hours life expectancy



Specification:



Input Voltage:

5VDC

Max Power Consumption:

34.56W per mtr

LED Quantity:

144 per mtr

LED Classification:

Pixel RGB SMD

IC Type

WS2811

Viewing Angle:

120°

Standard Reel Length:

1mtr

Custom Lengths Available:

Yes

Dimensions:

1000mm(L) x  12mm(W)

Operating Temperature:

-20 ~ +60°C

Storage Temperature:

-40~+80 °C

IP Rate:

non-waterproof,IP65,IP67,IP68
Material:

Super slim flexible PCB
PCB Color:

Black and White both avaliable
Flexibility:

360°
Brand:

SJ or OEM



Description:



 1.The tape is extremely thin with a depth of just 3mm. It has a 3M self-adhesive backing so

is easily applied to most smooth surfaces by simply removing the backing paper



2.The LEDs used in the tape are 3 Chip SMD LEDs like the ones uses to backlight the screens

of the latest Mobile Phones and MP4 Players



3.The LEDs are encapsulated in resin for a splashproof seal



4.There are 144 RGB LEDs per meter, you can control each LED individually.This is the digitally

addressable type of LED strip. You can set the color of each LED's red,green and blue



 5.The tape can be cut or joined, connections and cutting points are at 1 LED



Detailed Images:



144leds per meter ws2812B fully addressable LED pixel strip

144leds per meter ws2812B fully addressable LED pixel strip144leds per meter ws2812B fully addressable LED pixel strip144leds per meter ws2812B fully addressable LED pixel strip





Waterproof Level available:



IP40--Non waterproof ,for interior use



IP65---Epoxy coating,easy cut,exterior use



IP67---Silicone tube,need reseal after cut,exterior use



IP68---can work underwater



Check where led strips are used:



1.Edge lighting



2.Cabinet lighting



3.Cove lighting



4.Wall color wash lighting



5.Residential kitchens



6.Decorative lights for holiday, event, show, exhibition



7.Automobile and bicycle decoration



144leds per meter ws2812B fully addressable LED pixel strip144leds per meter ws2812B fully addressable LED pixel strip144leds per meter ws2812B fully addressable LED pixel strip



Trade Terms:



1)  Payment Terms: T/T or Western Unionl or Moneygram or Ali Excrow(Credit Card, Debit Card, Bank Transfer)



2) Lead Time:3-5 working days,subject to the order quantity .



3) Delivery Ways:DHL,Fedex ,TNT UPS,EMS door to door service,by sea,by air,etc.



4) 2 years warranty since the date of purchase our LED products.





Warranty Terms:



ShenZhen Shiji Lighting CO.,Ltd.



1)Our Warranty to You



v To be free from defects in material and workmanship under normal use and service

v Warranty period:24 months,effective from the date of shipment

v Warranty only for original perchaser for flex led strip



2)How to Get Our Warranty Service



To get warranty service from Shiji,you only need to:

v Provide us with purchase PI No. Part

v Provide us photoes for defective led

v When requested by Shiji,return the defective LED



3)Warranty Service



v Repair the defective LED product

v Replace the defective LED product



4)Exclusions from Our Warranty



v Any repair,replacement or alteration by a facility not approved in advance by Shiji.





Certificates:

144leds per meter ws2812B fully addressable LED pixel strip
