Specifications
1.PLC controll system2.material: 304 stainless steel
3.low power consumption
Salt Water Ice Block Machine MB300
1.Koller MB series ice block making machines
types of ice blocks: 5 kg/PC, 10kg/PC, 15kg/PC, 20kg/PC, 25kg/PC, 30kg/PC, 50kg/PC , 100kg/PC . Meanwhile, we also can produce in compliance with the customers' requirements.
1).Industrial ice block making machine structure: Compressor unit, ice making pool and cooling tower-water cooled system(air condenser-air cooled system).It is easy to install, just need to connect the water pipes between the three parts, and supply the power wire to the machine
2). Weight of ice:2.5kg,5kg..10kg..20kg….. also can be done as customers’ requirement.
|
Ice Size (kg)/pc |
Ice Dimension(mm) Thickness*Width*Height |
Freezing Time (hours) |
||||||||||
5 |
80*150*500 |
4.8 |
||||||||||
10 |
100*200*600 |
6 |
||||||||||
15 |
100*300*600 |
6 |
||||||||||
20 |
120*270*750 |
8 |
||||||||||
150*210*750 |
12 |
|||||||||||
25 |
120*330*750 |
8 |
||||||||||
150*200*1000 |
12 |
|||||||||||
30 |
120*300*1000 |
8 |
||||||||||
150*240*1000 |
12 |
|||||||||||
50 |
150*400*1000 |
12 |
||||||||||
100 |
250*500*1100 |
24 |
||||||||||
Model |
Capacity tons/24hours |
Compressor Power (KW) |
Compressor Brand |
Total Power (KW) |
Cooling way |
Outer Dimension |
MB10 |
1 |
4.5 |
Manevrop/Bitzer/ Refcomp |
6 |
Air/water Cooling |
Main unit and water tanK: 2820*1480*1040 |
MB20 |
2 |
8.1 |
Manevorp/Bitzer/ Refcomp |
11 |
Air/water cooling |
main unit:1630*720*1530 Water Tank: 2300*1430*1090 |
MB30 |
3 |
11.1 |
Bitzer/Refcomp/ Copeland |
14 |
Air/Water cooling |
Main unit: 1660*860*1450 water tank: 2460*1550*970 |
MB40 |
4 |
17.2 |
Bitzer/Refcomp/ Copeland |
22.5 |
water cooling |
Main unit: 1630*730*1520 water tank:4000*1356*900 |
MB50 |
5 |
22.1 |
Bitzer/Refcomp/ Copeland |
31 |
water cooling |
main unit:1630*830*1520 water tank:3700*1450*1100 |
MB60 |
6 |
23.5 |
Bitzer/Refcomp/ Copeland |
32 |
water cooling |
main unit:1750*900*1700 water tank:3100*1630*1420 |
MB80 |
8 |
31.4 |
Bitzer/Refcomp/ Copeland |
45 |
water cooling |
main unit: 2000*850*1300 water tank:5200*1850*1100 |
MB100 |
10 |
44.2 |
Bitzer/Refcomp/ Copeland |
58 |
water cooling |
main unit: 2300*1750*1300 water tank: 6000*1750*1300 |
MB150 |
15 |
62.5 |
Bitzer/Refcomp/ Copeland |
78 |
water cooling |
main unit:2300*1750*1300 water tank:8000*2100*1200 |
MB200 |
20 |
84.6 |
Bitzer/Refcomp/ Copeland |
96 |
water cooling |
main unit:2260*1350*1330 water tank: 9380*1770*1380 |
MB250 |
25 |
102 |
Bitzer/Refcomp/ Copeland/Hanbell |
125 |
water cooling |
main unit:2300*1500*1680 water tank: (8250*1980*1350)*2 |
MB300 |
30 |
112 |
Bitzer/Refcomp/ Copeland/Hanbell |
150 |
water cooling |
main unit:2260*1800*1480 water tank:(8770*1770*1125)*2 |
MB350 |
35 |
136 |
Bitzer/Refcomp/ Coepland/Hanbell |
190 |
water cooling |
main unit:2260*1800*1480 water tank:(9000*2100*1200)*3 |
MB800 |
80 |
262 |
Bitzer/Refcomp Copeland/Hanbell |
251 |
water cooling |
main unit:5500*2000*2000 water tank:(11600*2080*1400)*3 |
MB1000 |
100 |
328 |
Bitzer/Refcomp Copeland/Hanbell |
390 |
water cooling |
main unit:5500*2000*2000 water tank:(10000*2080*1400)*4 |
3. Product Description
Reasonable design for the ice moulds and salt water tank with stainless steel 304, save space, and easy to install;
Greatly save energy, only 80-85KW*H are consumed to produce one-ton ice;
Equipped with Siemens PLC central program control, which allows multiple functions such as automatic machine start and shut down; ice stopping production when the ice bins are full, Automatic water making up
Adopts the world's famous brand components, which will grantee the best refrigeration effect and working condition
Item |
Name of Components |
Brand Name |
Original Country |
1 |
Compressor |
BITZER/Refcomp |
Germany/Italy |
2 |
Ice moulds and salt water tank |
KOLLER |
China |
3 |
Water cooled condenser |
KOLLER |
|
4 |
Refrigeration components |
DANFOSS/CASTAL |
Demark/Italy |
5 |
PLC Program control |
SIMENS |
Germany |
6 |
Electrical components |
LG (LS) |
South Korea |
4. Installation for block ice machine:
1). Installing by the user: we will test and install the machine before shipment, all necessary spare parts, operation manual and CD are provided to guide the installation.
2).Installing by Koller engineers:
We can send our engineer to assist the installation and provide technical support and train your workers. The end-user should provide accommodation and round-trip ticket for our engineer.
5.Why choose us?
- So far, we have exported ice machines to 150 countries in the world.
- Excellent Brand of Chinese Ice Machine Industry.
- The Drafting Committee of National Ice Machine Industry Standard.
- Produce & Academic Research Strategy Cooperating Partner with Tsinghua University.
- Independent after-sales department, 8 engineers are ready to service abroad.
