Industrial Machinery Salt Water Ice Block Machine Mb300

Industrial Machinery Salt Water Ice Block Machine Mb300 thumbnail-1
Industrial Machinery Salt Water Ice Block Machine Mb300 photo-1
US$ 1 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Capacity:
30 tons capacity per day
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Guangzhou Koller R & E Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Capacity 30 tons capacity per day
Place of Origin Guangdong, China
Brand Name Koller
Model Number MB300
Ice Shape Other, ice block
Voltage 380V/50HZ/3P or 220V/60HZ/3P
Power(W) 112000
Dimension(L*W*H) 2260mm*1800mm*1480mm
Weight About 3000kg
Certification CE
Warranty 12 months
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Digital temperature controlled
2.304 stainless steel as main material



Industrial machinery Salt Water Ice Block Machine mb300 Ice Block Machine MB300



Industrial machinery Salt Water Ice Block Machine mb300



1.Koller MB series ice block making machines have the following types of ice blocks: 5 kg/PC, 10kg/PC, 15kg/PC, 20kg/PC, 25kg/PC, 30kg/PC, 50kg/PC , 100kg/PC . Meanwhile, we also can produce in compliance with the customers' requirements.



2..Industrial ice block making machine structure: Compressor unit, ice making pool and cooling tower-water cooled system(air condenser-air cooled system).It is easy to install, just need to connect the water pipes between the three parts, and supply the power wire to the machine





  Industrial machinery Salt Water Ice Block Machine mb300





3. Weight of ice:2.5kg,5kg..10kg..20kg….. also can be done as customers’ requirement.



Standard Ice Block Size:

Ice Size(kg) Ice Dimension(mm)
5 80*160*500
10 100*200*610
15 100*300*610
15 120*255*610
20 120*300*750
25 120*350*750
25 150*300*750
30 150*300*950
50 150*450*1000
100 220*550*1100




Ice  moulds

Industrial machinery Salt Water Ice Block Machine mb300


Cooling Tower
Industrial machinery Salt Water Ice Block Machine mb300


Ice block machine can be equipped with crane system on your requirement.


Industrial machinery Salt Water Ice Block Machine mb300
Industrial machinery Salt Water Ice Block Machine mb300


 Industrial machinery Salt Water Ice Block Machine mb300



4.Koller ice block machine Working Parameter:




Model Capacity(Tons/24Hours) Compressor Power(KW) Compressor Brand(France/Germany/Taiwan/Italy) Total Power(kw) Cooling Way Outer Dimension(L*W*H)(MM)
MB10 1 4.5 Bitzer/Manevrop/Refcomp 6 Air/Water Cooling Main Compressor Unit and Water Tank: 2820*1480*1040
MB20 2 8.1 Bitzer/Manevrop/Refcomp 11 Air/Water Cooling Main Unit:1630*720*1530
Salt Water Tank: 2300*1430*1090
MB30 3 11.1 Bitzer/Copeland/Refcomp 14 Air/Water Cooling Main Unit:1660*860*1450
Salt Water Tank:2460*1550*970
MB40 4 17.2 Bitzer/Copeland/Refcomp 22.5 Water Cooling Main Unit:1630*730*1520
Salt Water Tank:4000*1356*900
MB50 5 22.1 Bitzer/Copeland/Refcomp 31 Water Cooling Main Unit:1630*830*1520
Salt Water Tank:3700*1450*1100
MB60 6 23.5 Bitzer/Copeland/Refcomp 32 Water Cooling Main Unit:1750*900*1700
Salt Water Tank:3100*1630*1420
MB80 8 31.4 Bitzer/Copeland/Refcomp 45 Water Cooling Main Unit:2000*850*1300
Salt Water Tank:5200*1850*1100
MB100 10 44.2 Bitzer/Copeland/Refcomp 58 Water Cooling Main Unit:2300*1750*1300
Salt Water Tank:6000*1750*1300
MB150 15 62.5 Bitzer/Copeland/Refcomp 78 Water Cooling Main Unit:2300*1750*1300
Salt Water Tank:8000*2100*1200
MB200 20 84.6 Bitzer/Copeland/Refcomp 96 Water Cooling Main Unit:2260*1350*1330
Salt Water Tank:9380*1770*1380
MB250 25 102 Bitzer/Copeland/Hanbel/Refcomp 125 Water Cooling Main Unit:2300*1500*1680
Salt Water Tank:(8520*1980*1350)*2
MB300 30 112 Bitzer/Copeland/Hanbel/Refcomp 150 Water Cooling Main Unit:2260*1800*1480
Salt Water Tank:(8770*1770*1125)*2
MB350 35 136 Bitzer/Copeland/Hanbel/Refcomp 190 Water Cooling Main Unit:2260*1800*1480
Salt Water Tank:(9000*2100*1200)*3
MB800 80 262 Bitzer/Copeland/Hanbel/Refcomp 251 Water Cooling Main Unit:5500*2000*2000
Salt Water Tank:(11600*2080*1400)*3
MB1000 100 328 Bitzer/Copeland/Hanbel/Refcomp 390 Water Cooling Main Unit:5500*2000*2000
Salt Water Tank:(10000*2080*1400)*4





5. Product Description





Reasonable design for the ice moulds and salt water tank with stainless steel 304, save space, and easy to install;



Greatly save energy, only 80-85KW*H are consumed to produce one-ton ice;



Equipped with Siemens PLC central program control, which allows multiple functions such as automatic machine start and shut down; ice stopping production when the ice bins are full, Automatic water making up





Adopts the world's famous brand components, which will grantee the best refrigeration effect and working condition





Item

Name of Components

Brand Name

Original Country

1

Compressor

BITZER/Refcomp

Germany/Italy

2

Ice moulds and salt water tank

KOLLER



China

3

Water cooled condenser

KOLLER

4

Refrigeration components

DANFOSS/CASTAL

Demark/Italy

5

PLC Program control

SIMENS

Germany

6

Electrical components

LG (LS)

South Korea









6. Installation for block ice machine:





1). Installing by the user: we will test and install the machine before shipment, all necessary spare parts, operation manual and CD are provided to guide the installation.



 2).Installing by Koller engineers:



We can send our engineer to assist the installation and provide technical support and train your workers. The end-user should provide accommodation and round-trip ticket for our engineer.









7.Why choose us?

  • So far, we have exported ice machines to 150 countries in the world.
  • Excellent Brand of Chinese Ice Machine Industry.
  • The Drafting Committee of National Ice Machine Industry Standard.
  • Produce & Academic Research Strategy Cooperating Partner with Tsinghua University.
  • Independent after-sales department, 8 engineers are ready to service abroad.

 Industrial machinery Salt Water Ice Block Machine mb300



Industrial machinery Salt Water Ice Block Machine mb300
