1000kg Block Ice Machine MB10
-1. Block ice
We design 5~100kg ice block for different capacity ice machine, meanwhile, we can design according to our customers' requirments.
Here are our regular block ice size:
| Ice weight | ice size L*W*H (mm) | ice making time | Times |
| 5kg | 80*165*500 | 4.8 | 5 |
| 10kg | 100*205*610 | 6 | 4 |
| 10kg | 120*160*610 | 8 | 3 |
| 15kg | 100*320*610 | 6 | 4 |
| 15kg | 120*265*610 | 8 | 3 |
| 20kg | 120*320*750 | 8 | 3 |
| 25kg | 120*360*750 | 8 | 3 |
| 25kg | 145*315*750 | 12 | 2 |
| 30kg | 145*300*950 | 12 | 2 |
| 50kg | 145*460*1000 | 12 | 2 |
| 50kg | 180*380*1000 | 16 | 1.5 |
| 100kg | 210*550*1200 | 24 | 1 |
-2. Ice mould and salt water tank
For salt water block ice machine, we use all SUS304 stainless steel for ice mould and ice water tank design. It can keep long life span for the whole machine, stainless steel is the best material for anti-corrosion and keep the cleanliness of the block ice.
-3. Machine unit.
We have two cooling way for ice block machine, water cooling and air cooling, the way for choosing cooling way is based on the machine capacity, machine installation environment and requirments of our customers. Water cooling way will equip with a cooling tower.
-4. Main components and material of machine
| Block ice machine | ||||||||||||
| Model |
Capacity (ton/24h) |
cooling way |
Compressor brand |
Compressor power (HP) |
Circulate water pump power(KW) |
Cooling water pump power (KW) |
Cooling motor power (KW) |
Ice weight |
cooling Tower capacity |
Machine size(mm) |
Salt water tank size (mm) |
|
| MB10 | 1 | air cooling | Maneroupe/Bitzer/Copeland | 6 (4) | 1.1 | / | 0.18 | 5kg/10kg | # | 2640*1500*1120 | ||
| MB20 | 2 | air/water | Maneroupe/Bitzer/Copeland | 12 (9) | 1.5 | 1.1 | 0.37 | 5kg/10kg | 10T | 1560*790*1520 | 2450*1010*960 | |
| MB30 | 3 | air/water | Bitzer/Copeland | 14 | 2.2 | 1.5 | 0.55 | 5kg/10kg | 15T | 1570*780*1520 | 2550*1320*1100 | |
| MB40 | 4 | water cooling | Bitzer/Bock/Copeland | 23 (20) | 3 | 1.5 | 0.55 | 10kg | 20T | 1870*870*1700 | 2850*1600*1100 | |
| MB50 | 5 | water cooling | Bitzer/Bock/Copeland | 28 (25) | 4 | 2.2 | 0.75 | 10kg | 25T | 1870*870*1730 | 3600*1450*1200 | |
| MB60 | 6 | water cooling | Bitzer/Bock/Copeland | 28 (25) | 4 | 2.2 | 0.75 | 25kg | 30T | 1870*900*1730 | 3290*2007*1300 | |
| MB80 | 8 | water cooling | Bitzer/Bock/Copeland | 44 (40) | 5.5 | 4 | 1.5 | 25kg | 40T | 2080*960*1750 | 5250*1620*1170 | |
| MB100 | 10 | water cooling | Bitzer/Bock/Copeland | 50 | 5.5 | 4 | 1.5 | 25kg | 50T | 2360*1060*1800 | 6080*1700*1130 | |
| MB150 | 15 | water cooling | Bitzer/Bock/Copeland | 2*40 | 7.5 | 5.5 | 1.5 | 25kg | 60T | 2670*1510*1710 | 7000*2000*1130 | |
| MB200 | 20 | water cooling | Bitzer/Bock/Copeland | 3*34 (32) | 11 | 5.5 | 1.5 | 25kg | 80T | 2470*1350*1330 | 9985*2007*1200 | |
| MB250 | 25 | water cooling | Bitzer/Bock/Copeland | 3*44 (40) | 15 | 5.5 | 1.5 | 30kg | 100T | 2500*1700*1950 | 10400*2657*1500 | |
| MB300 | 30 | water cooling | Bitzer/Bock/Copeland | 3*50 | 11*2 | 7.5 | 2.2 | 50kg | 125T | 3870*1770*1920 | 7785*1973*1650*2 | |
How many countries in the world have your Koller machines entered?
Till now, Koller products has been exported to more than 150 countries and areas in the world, such as Philippines, Malaysia in Southeast Asia, Saudi Arabia, Dubai in Middle East, Spain, Hungary, England in Europe, Nigeria, Benin, Congo, South Africa in Africa, U.S.A in North America, Chile, Peru, Paraguay in South America etc.
-1. Q: Power supply: the power can be single phase?
No, it need the industrial supply power for the whole plant, say that 3phase power, 380~420V,50Hz, 3P or 220~240V, 60Hz, 3P.
-2. Q: If this is my first time to invest ice plants, then how should I prepare my factory?
Water treatment to pure water è ice machine to make ice è
digital scale and sealing machine to pack ice bags è cold room to store ice
Water treatment to make pure water: https://img13.fr-trading.com/product/60126862351-0/Pure_water_making_machine_for_drinking_ice_plant.html
Cold room to store ice: https://img13.fr-trading.com/product/60125613772-214059528/Koller_cood_storage_room_to_keep_ice.html
Installation:
1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts operation manual and CD are provided to guide the installation.
2). Installing by Koller engineers:
(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.
(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready. Meanwhile, we will provide you a Tool List with the machine when delivery.
(3) All spare parts are provided according to our standard. During installation period, any shortage of parts due to the actual installation site, the buyer is required to afford the cost, such as water pipes.
(4) 2~ 3 workers are required to assist the installation for big project.
(5) Any delay due to customer’s reason, it will be charged from the 8th day, USD100/day for one person as installation fee. Free of charge for one week.
Koller specialize in ice machine research, design, manufacture for 10 years since 2004, our products sell all over the world, and you can see many refrigeration equipments in your daily life, we produce block ice machine, tube ice machine , cube ice machine, plate ice machine , flake ice machine and cold room. Koller is one of biggest ice machine producer in China, you can buy different kinds of ice machine from us for different applications.
