MB30 Ice Block Machine
-1. Block ice
We design 5~100kg ice block for different capacity ice machine, meanwhile, we can design according to our customers' requirments.
Here are our regular block ice size:
| Ice weight | ice size L*W*H (mm) | ice making time | Times |
| 5kg | 80*165*500 | 4.8 | 5 |
| 10kg | 100*205*610 | 6 | 4 |
| 10kg | 120*160*610 | 8 | 3 |
| 15kg | 100*320*610 | 6 | 4 |
| 15kg | 120*265*610 | 8 | 3 |
| 20kg | 120*320*750 | 8 | 3 |
| 25kg | 120*360*750 | 8 | 3 |
| 25kg | 145*315*750 | 12 | 2 |
| 30kg | 145*300*950 | 12 | 2 |
| 50kg | 145*460*1000 | 12 | 2 |
| 50kg | 180*380*1000 | 16 | 1.5 |
| 100kg | 210*550*1200 | 24 | 1 |
-2. Ice mould and salt water tank
For salt water block ice machine, we use all SUS304 stainless steel for ice mould and ice water tank design. It can keep long life span for the whole machine, stainless steel is the best material for anti-corrosion and keep the cleanliness of the block ice.
-3. Machine unit.
We have two cooling way for ice block machine, water cooling and air cooling, the way for choosing cooling way is based on the machine capacity, machine installation environment and requirments of our customers. Water cooling way will equip with a cooling tower.
-4. The manufacture process of Koller ice block machine
Main Components for Ice Block Machine:
Brand Name Accessories
Layout of Ice Block Machine
All of our ice machines are packed into wooden case, for cold room, it will completely knocked down to save sapce before shipping.
Installation:
Koller MB Series Ice Block Machines are new-type design with high efficiency and stable capacity, performance well in Tropical area such as Africa, Middle East and Oceania. The ice block machine adopts separate design for the ice block machinery unit and water tank part, which is easy to install and maintenance. Meanwhile you just need to connect water pipes and power lines to the machine.
Installation:
1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts operation manual and CD are provided to guide the installation.
2). Installing by Koller engineers:
(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.
(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready. Meanwhile, we will provide you a Tool List with the machine when delivery.
(3) All spare parts are provided according to our standard. During installation period, any shortage of parts due to the actual installation site, the buyer is required to afford the cost, such as water pipes.
(4) 2~ 3 workers are required to assist the installation for big project.
(5) Any delay due to customer’s reason, it will be charged from the 8th day, USD100/day for one person as installation fee. Free of charge for one week.
Our Services
If I buy your machine, how could I install? Do you have someone to help the installation?
•A: Before shipping, we will install and test the machine well.
•B: All needed CD and operation manual will be provided to guide the installation step by step.
•C: If requested, we will send one engineer to guide the installation and train your staff how to operate. You just need to afford the round-trip tickets, visa fee and the accommodation and food at the installation for our engineer.
•D: Sometimes a Chinese translator will be needed in your local site.
If there are some problems with the machine, how can you help to solve the problems?
We guarantee the warranty for 12 months. Regarding after-sales service, once machine is out of work, you only need to send us pictures or videos about the fault, we will get back to you with the solution within 24 hours. If the parts is broken and proved by our engineer for non-personal reason, we will offer free parts to replace within guarantee period by DHL, usually 3~4 days to arrive your factory; if it is beyond guarantee period, we will charge market price for the new parts.
What's the main Products in Koller ice machine company?
Yes, there are various products in Koller Company
•Cube Ice Machine
•tube ice machine
•Block ice machine
•Flake ice machine
•Plate ice machine
•Cold room
How many countries in the world have your Koller machines entered?
Till now, Koller products has been exported to more than 150 countries and areas in the world, such as Philippines, Malaysia in Southeast Asia, Saudi Arabia, Dubai in Middle East, Spain, Hungary, England in Europe, Nigeria, Benin, Congo, South Africa in Africa, U.S.A in North America, Chile, Peru, Paraguay in South America etc.
-1. Q: Power supply: the power can be single phase?
No, it need the industrial supply power for the whole plant, say that 3phase power, 380~420V,50Hz, 3P or 220~240V, 60Hz, 3P.
-2. Q: If this is my first time to invest ice plants, then how should I prepare my factory?
Water treatment to pure water è ice machine to make ice è
digital scale and sealing machine to pack ice bags è cold room to store ice
Water treatment to make pure water: https://img13.fr-trading.com/product/60126862351-0/Pure_water_making_machine_for_drinking_ice_plant.html
Cold room to store ice: https://img13.fr-trading.com/product/60125613772-214059528/Koller_cood_storage_room_to_keep_ice.html
Koller specialize in ice machine research, design, manufacture for 10 years since 2004, our products sell all over the world, and you can see many refrigeration equipments in your daily life, we produce block ice machine, tube ice machine , cube ice machine, plate ice machine , flake ice machine and cold room. Koller is one of biggest ice machine producer in China, you can buy different kinds of ice machine from us for different applications.
