3 Tons Dry And Clean Flake Ice Machine For Fishery
- 50 Set / Sets per Month
- Guangzhou Port
- T/T Credit Card PayPal
- New York slide valve displacement sensor 534D1251H01, maintenance of lubrication system malfunction for turbine compressor
- New shaft seal 534M0163G02, York TDSH193 compressor disassembly and maintenance parts
- 200kg Dry ice pellets making machine for dry ice production
- New York Liquid Flowmeter 024W26116-002 Flow Switch HF68 Mechanical Target
- New slide valve potentiometer coupling 111Q0451313
- New Kunteng 5 motherboard 649C1152G01 York FRICK circuit board 649C1158G01
Product Details
Condition: | New | Capacity: | 3000kg | Place of Origin: | Guangdong, China |
Brand Name: | Koller | Model Number: | KP30 | Ice Shape: | Flake Ice |
Voltage: | 380V/220V | Power(W): | 9000W | Dimension(L*W*H): | 1650mmx1460mmx2186mm |
Weight: | 470KG | Certification: | CE | Warranty: | 12 months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
3 tons Flake Ice Machine For Fishery---KP30
-1. Flake ice
Flake ice is made of the fresh water , in some cases can be directly made from brine water. Thickness between 1.8mm to 2.2 mm, irregular shape with diameters from 12 mm to 45 mm.
Flake ice is thin and dry, without any edges and corners, which can not hurt chilled food.
-2. Evaporator
The evaporator of the flake ice machine is a vertically placed drumshape stainless steel container, equipped with the rotating blade which spins and scratches the ice of the inner wall of evaporative. When operating, the principal shaft and blade spins anticlockwise pushed by the reducer. Water is sprayed down from the sprinkler; ice is formed from the water brain on the inner wall.
-3. . Microcomputer intelligent control:
The machine is using PLC control system with world famous brand components, which control the whole ice making process, meanwhile it can protect the machine when there are water shortage, ice full, high /low pressure alarm, and motor reversal in order to guarantee the machine run stably with less faults.
-4. The main components of the flake ice machine.
-5. Application:
5.1 Brinewater flake ice machine can make ice directly from the sea water. This ice can be used in fast cooling of fish and other sea products. The fishing industry is the largest user of flake ice machines. Flake ice can lower the temperature of cleaning water and sea products, therefore it resists the growth of bacteria and keeps the seafood fresh.
5.2 . Because of its large contact and less damage with refrigerated materials, it is also applied in vegetable, fruit and meat storing and transporting.
5.3 In most cases of biosynthesis and chemosynthesis, flake ice is used to control the reaction rate and maintain the liveness. Flake ice is sanitary, clean with rapid temperature reduction effect.
5.4 Flake ice is used as the direct source of water in concrete cooling process, more than 80% in weight. Concrete will not crack if has been mixed and poured in constant and low temperature.
6. Layout of the machine
If I buy your machine, how could I install? Do you have someone to help the installation?
•A: Before shipping, we will install and test the machine well.
•B: All needed CD and operation manual will be provided to guide the installation step by step.
•C: If requested, we will send one engineer to guide the installation and train your staff how to operate. You just need to afford the round-trip tickets, visa fee and the accommodation and food at the installation for our engineer.
•D: Sometimes a Chinese translator will be needed in your local site.
If there are some problems with the machine, how can you help to solve the problems?
We guarantee the warranty for 12 months. Regarding after-sales service, once machine is out of work, you only need to send us pictures or videos about the fault, we will get back to you with the solution within 24 hours. If the parts is broken and proved by our engineer for non-personal reason, we will offer free parts to replace within guarantee period by DHL, usually 3~4 days to arrive your factory; if it is beyond guarantee period, we will charge market price for the new parts.
How many countries in the world have your Koller machines entered?
Till now, Koller products has been exported to more than 150 countries and areas in the world, such as Philippines, Malaysia in Southeast Asia, Saudi Arabia, Dubai in Middle East, Spain, Hungary, England in Europe, Nigeria, Benin, Congo, South Africa in Africa, U.S.A in North America, Chile, Peru, Paraguay in South America etc.
-1. Q: Power supply: the power can be single phase?
No, it need the industrial supply power for the whole plant, say that 3phase power, 380~420V,50Hz, 3P or 220~240V, 60Hz, 3P.
-2. Q: If this is my first time to invest ice plants, then how should I prepare my factory?
Water treatment to pure water è ice machine to make ice è
digital scale and sealing machine to pack ice bags è cold room to store ice
Water treatment to make pure water: http://preview.china.cn/product/60126862351-0/Pure_water_making_machine_for_drinking_ice_plant.html
Cold room to store ice: http://preview.china.cn/product/60125613772-214059528/Koller_cood_storage_room_to_keep_ice.html
Koller specialize in ice machine research, design, manufacture for 10 years since 2004, our products sell all over the world, and you can see many refrigeration equipments in your daily life, we produce block ice machine, tube ice machine , cube ice machine, plate ice machine , flake ice machine and cold room. Koller is one of biggest ice machine producer in China, you can buy different kinds of ice machine from us for different applications.
