Specifications
The tank body has a big capacity, usable capacity is up to 480 m3.Using the corrugated sheet structure, and with the “five stages purification, control of total access, total Explosion-proof circuit”, the mud circulation tank is well received by the drilling crew.
The main features
♦ With the corrugated sheet structure, the tank body has the advantage of high strength, elegant appearance, and reduce the weight of tank body.
♦ The solids control equipments are rationally distributed, and up to five stages purification(rough screening, degas, desand, desilt and centrifugation),and optimum the performance of the mud.
♦With the zinc-coated steel grating, the tank level is fine-looking, portable, corrosion-resistant, and so on.
♦ The tank body are connected by pneumatic type unions and glass steel tubes, so they have the advantages of fine-looking, installation easily, reliable steel, and so on.
♦ The tank body has a big capacity, usable capacity is up to 480m3.
♦ The water supply is automatic control, and every tank or compartment can be supplied water at the same time.
♦ Used ocean specialized paint for corrosion protection and well materials, the tank has high surface strength, and is fine-looking, wear well.
| Technical Parameters of FG mud tank | |||||
| Model | Total volume | Max. capacity | Mixing capacity | QTY | Dimension |
| FG60 | 60m3 | 80m3/h | 100m3/h | 2 | 8.5×2.4×2.5m |
| FG80 | 80m3 | 100m3/h | 120m3/h | 2 | 10.5×2.4×2.5m |
| FG120 | 120m3 | 160m3/h | 180m3/h | 3 | 10.5×2.4×2.5m |
| FG160 | 160m3 | 200m3/h | 200m3/h | 4 | 10.5×2.4×2.5m |
| FG200 | 200m3 | 200m3/h | 200m3/h | 5 | 10.5×2.4×2.5m |
| FG240 | 240m3 | 240m3/h | 240m3/h | 6 | 10.5×2.4×2.5m |
| FG300 | 300m3 | 240m3/h | 240m3/h | 7 | 11.5×2.4×2.5m |
| FG350 | 350m3 | 240m3/h | 240m3/h | 8 | 11.5×2.4×2.5m |
| FG400 | 400m3 | 240m3/h | 240m3/h | 9 | 11.5×2.4×2.5m |
